Coal Drying Machine for Coal Gangue and Lignite Coal Drying Price in China

Coal drying machine for coal gangue and lignite coal drying price in China

Coal drying machine is a type of industrial dryer employed to reduce or minimize the liquid moisture content of the material, it is handled by bringing it into direct contact with a heated gas.

Coal drying machine structure:

Coal drying machine is formed by rotary body, lifting blade, driving device, supporting device and bigger gear, smaller gear, motor and reducer.

Coal drying machine working principle:

Due to the stickiness of the coal slurry, it can be divided into several working areas.

First, guide area where the wet coal slurry meets the hyperthermia hot air and its moisture evaporates fast. As the material is stirred by the shoveling plate of the big lead angle, the bonding can not be formed and was sent to another working area.

Second, cleaning area where the wet coal slurry is raised by the shoveling plate and become the material curtain type. So as the material drops down, it is likely to be bound with the rotary drum wall which can be cleaned by the cleaning device reasonable. In this process, the cleaning device can break the clotting which increases the heat exchange area thus improves the drying speed.

Third, slant flitch area where is wet slurry is in the state of low moisture and loose condition. The material here won't bond. After the heat exchange the material meet the moisture condition demand, and then goes to the last area-discharging area. There is no shoveling plate here. The material rolls and slides to the dumping mouth and the whole drying process are finished.

Coal drying machine technical parameter:

coal drying machine application:


Coal drying machine can dry many kinds of materials which contain moisture, such as coal, coal slurry, slag, industrial waste, and clay stone. They are widely used in building materials, metallurgy and chemical industry.

Heat source: coal, gas, electricity, oil and wind power,etc.

 Coal drying machine shipping:

Derui service:

Installation and guidance

When the machine arrives at your company, we will dispatch our technicians to your company to guide the installation and commissioning at site. User should pay for the following fees air tickets, boarding and lodging and traffic in client’s factory. Allowance is about 70USD per day.

Technical training

We provide free technical training service to your stuff. Training content contains the main work principle of machine, operating regulations, maintenance methods and steps, safety, etc.

Warranty: one year (not include man-made damaged).

In order to help you to recommend suitable coal drying machine , can you tell me the following information in your inquiry?

1. What is the material you want to dry?

2. What is the moisture of the feed materials?

3. What is the final moisture you want to get?

4.What is the hear source?(firewood, coal, heat gas or electricity)

4. What is the production capacity per hour or per day?
