Semi-auto finger joint production line with pretty competitive price
Model | MXZ3515 Finger joint shaper | MXZ3515T Finger joint shaper with automatic gluing device |
Table Size(LxW) | 850x600mm | 850x600mm |
Max working size(LxWxH) | 850x80x150mm | 850x80x150mm |
Min working thickness | 150x20x30mm | 150x20x30mm |
Cutter speed | 6000r/min | 6000r/min |
Draw saw speed | 5600r/min | 5600r/min |
Trimming saw speed | 5000r/min | 5000r/min |
Shaper blade diameter | 160mm | 160mm |
Shaper spindle diameter | 70mm | 70mm |
Main saw blade size | 255mm | 255mm |
Cutter motor power | 11kw | 11kw |
Saw motor power | 5.5kw | 5.5kw |
Feeder motor power | 0.375kw | 0.375kw |
Total power | 16.12kw | 16.87kw |
Working air pressure | 0.5-0.8Mpa | 0.5-0.8Mpa |
Net weight | 2000kg | 2200kg |
Overall diamensions | 2380×1700×1400mm | 2580×1700×1400mm |
Model | MHB1560 Finger joint assembler |
Max.assembled size | 6200x150x80mm |
ing length one time | 6200mm |
ing width | 150mm |
ing thickness | 80mm |
ing length | 2000 mm |
1. Guide rail of finger joint shaper’s conveyor is japan precision linear guide rail to gurantee the shaping accuracy .
2. The design for finger joint shaper is double blades+tooth-tenon knife assembly to provide high precision.
3. The conveyor table of finger joint shaper adopts German pneumatic hydraulic conveyor system to control bakc and forth ,smoothly,low maintenance,high quality .
4. The second push part of finger joint assembler adopts long+short double pushing board design,by this kind of structure ,it can assemble very short workpiece to reduce the cost .
5. Whole machine is conveniently operated by PLC Central integrated programmable controller.
Qingdao Steeler Woodworking Machinery Co., Ltd is a professional Manufacturer of various kinds of Sanding Machine, Polishing Machine and other mechanical equipment. The company’s sanding machine series is integrated with Germany, Italy and Taiwan's good mechanical properties, structure and the advanced polishing machine is not only draw lessons from the foreign advanced technology but also and highlights the Steeler people’s innovation, enterprising spirit, continuous research and development, making our polishing machine series the industry's leading edge products.
We have already approved the ISO9000 certification and we are awarded the "National AAA Grade Credit Enterprise" Brand in China. A capable R&D team, strong processing ability, reliable quality assurance, strict testing ensure the company win trust of users.
Rich experience, sophisticated design, advanced manufacturing technology, the company continuously adapt to the market and provide products with better design, performance, efficiency and improved after-sale service, which is the Goal of Steeler people!
