Stone broken equipment competitive price applied to construction limestone roller crusher machine
Double Roller Crusher is Our Patent Product
Double Roller Crusher Application
1. Manda Machinery Plant engaged in manufacturing crusher for 18 years.
2. It applies to cement, chemical industry, electric industry, metallurgy, construction, refractory material etc.
3. It is usually used in middle and fine crushing stage to crush medium hardness materials including coal,wood,limestone, furnace slag, coke, steel slag, salt, shale, good used in all kinds of ore, stone, rock fine crushing.
Double Roller Crusher Working Principle
Adjustment of discharging-material size: The wedge-shaped or gasket control is installed between two roll wheels. There is adjusting bolt in the top of the control. The wedge makes the active roll wheel away from fixable wheel, while the adjusting bolt is pulling up the wedge, this make the gap in the two roll wheels and discharging-materials size larger. When the wedge is pulled down, the active roll wheel under the action of holddown spring makes the gap and discharging become smaller. The gasket control trough regulates the quantity or thickness of the gasket to adjust the size of discharging-materials.
Double Roller Crusher Advantages
1. Reversible structure, good crushing effect.
2. Low initial & running cost, resources saving.
3. Taking electric and torque converter double overload protection to improve its reliability and safety.
4. Fixed spacing between two rollers of double roller crusher makes it stable to discharge.
5. All roller bearings of double roller crusher are lubricated concentrated with lubricating grease pump, more convenient and faster.
6. Reasonable design for the shape of tooth plate and high-qualified wear resistant material extends the working life of double roller crusher.
Industrial Roller Crusher Main Technical Data:
Model |
Feeding size |
Discharging size |
Capacity |
Motor power |
Weight |
Dimension |
2PG400×250 |
<35 |
≤2-8 |
2-10 |
2×5.5 |
1.3 |
2110×870×810 |
2PG610×400 |
<65 |
≤2-20 |
5-20 |
2×15 |
3.9 |
3510×1420×1030 |
2PG750×500 |
<75 |
≤2-25 |
10-40 |
2×18.5 |
9.5 |
4210×1630×1260 |
2PG800×600 |
<80 |
≤2-25 |
12-45 |
2×22 |
10.8 |
4505×1780×1320 |
2PG1000×700 |
<100 |
≤3-30 |
20-65 |
2×30 |
14.9 |
5310×2175×1595 |
2PG1200×800 |
<120 |
≤3-35 |
35-80 |
2×37 |
25.5 |
6290×2270×1870 |
2PG1500×800 |
<130 |
≤3-45 |
50-120 |
2×75 |
33.7 |
7460×2410×2290 |
2PG1600×1000 |
<150 |
≤3-50 |
60-140 |
2×90 |
41.2 |
8220×2680×2475 |
Our factory persists in the principle of "Leading Technology, Excellent Quality, Reasonable Price and Thoughtful Service," sticks to the development concept of "Quality First, Honest & Credible and Win-Win Situation", and aims at customer satisfaction. Customers at home and abroad are warmly welcome to visit our factory for consultation and negotiation.
We are eager to suggest you the most suitable machine type after know the details request below:
1. What's the material to be crushed ?
Soft stone(coal,dolomite,limestone) or hard stone(granite,basalt,river pebble)?
2. What's the input size of the material?
3. What's the output size you need?
4. What's the capacity you want? How many tons or cubic meters per hour?
