Specifications
soybean oil making press machine1.Complete production line
2.Mature technology
3.Getting senior cooking oil
4.ISO9001,BV
Low invest soybean oil making press machine
Pretreatment and pre-pressing technology
The techmology of my company for pretreatment and pre-pressing which mainly include the cleaning ,extrusion,flaking,decrustation and pre-pressing and so on .Considering the different characteristic of oil seeds and the customer requirements,we can provide you the special design,in order to adjust the oilseed to the optimun state ,which will improve the oil yield and oil and cake quality ,can provide the best raw ,materials for the following section.
Technological process introduction
1.Soybean pretreatment flow chart:
Soybean→Materials dosing →Magnetic separation→Cleaning→crusher→flaker→ Extrusion Puffing →Counter-current drying→To leaching plant
2. Main process description:
Metering:
Using special equipment, stable production measurement, used to adjust flow and measuring the total production, and can achieve the cumulative weighing, transient measurement and the purpose of cost accounting, accurate measurement, high precision.
Metering process
Cleaning:
In order to obtain high effective cleaning, ensure good work condition and production stability, high
efficient vibration screen was used in the process to separate big and small impurity. Suction type gravity
stoner removing machine was applied to remove the shoulder stone and earth, and magnetic separation
equipment without power and exhaust system were used to remove iron. Dust removing wind net is installed.
Vibration cleaning sieve
Stone separator:
Crushing:In order to ensure good softening and flaking effect, soy is generally broken up uniformly to
5~6 flakes and water distribute uniformly during softening, and flakes is thin and burliness.
Crushing section
Extrusion process:
Adopting the bulking machine can both improve the yield of rice bran oil and reduce the consumption.
The extrusion puffing, on the one hand, can make solution lipase in the rice bran passivated under high
temperature and high pressure condition,then prevent the rice bran oil rancidity; On the other hand, the
extrusion puffing can make rice bran be porous material grain, and increases the materials bulk density,
then improve the permeability and leaching rate which solvent reacts to the material.
Extrusion section
Flaking:
Flaking means a certainty granularity of soy lamella was prepared for flaked of about 0.3 mm, the oil
of raw material can be extracted in the shortest time and maximum, and residual oil was less than 1%.
Drying : The puffed rice bran contains about 12% water, and the best moisture for leaching process is
7-9%, therefore, there must be effective drying means to achieve the best leaching moisture.Adopting
counter-current dryer can make water and temperature meet with follow-up process requirements, and
improve the oil yield, as well as oil quality.
3.Process feature:
Pretreatment process feature:
1) Different combinations of process can process various oil plants in one workshop.
2) Use special intensified pretreatment technology for aroma peanut oil to make it more aroma.
3) Adopt advanced and reliable shelling technology to meet higher requirements for protein content in meal.
4) Extrusion treatment is used for raw materials with hard extraction, large-sized powder, and large capacity, which can reduce residual oil and solvent consumption, and increase the capacity by 50-80%.
5) The new technology of shelling and low-temperature treatment can ensure high protein and least denaturation.
4. Economic and technical parameters
Steam consumption:Soybean≤90kg/t Materials(Soybean moisture12%,Temperature:20°C)
Power consumption:365.95KW(Installed power)
Soybean extrusion cake quality:
Moisture ≤10%
Temperature 55°C~60°C
Oil content 19-24%
