Herbal extraction tank with steam distillation
Usage: The equipment serves as normal pressure, temperature dip, thermal influx and compel lent cycle, infiltration and extraction of aroma oil and reclaim of organic solvent, etc. in such industries as pharmacy, vegetable, animal, food and chemistry, especially effective in the case of dynamic extraction or inverse extraction, featuring short time of extraction and high pharmacy content.
The matching facilities including:
Collecting machine, condenser, cooler, filter, oil-water separator and cylinder operating plate.
Technology parameter
Model and specification | TQ-Z-1 | TQ-Z-2 | TQ-Z-3 | TQ-Z-4 | TQ-Z-6 | TQ-Z-8 |
Volume(L) | 1200 | 2300 | 3200 | 4300 | 6300 | 8500 |
Designed pressure inside pot(Mpa) | 0.09 | |||||
Jacket design pressure(Mpa) | 0.3 | |||||
Material imputting diameter(mm) | 400 | 400 | 400 | 500 | 500 | 500 |
Heating area(m2) | 3 | 4.7 | 6.8 | 8 | 10 | 12 |
Condensing area(m2) | 4 | 5.4 | 8 | 10 | 10 | 15 |
Cooling area(m2) | 1 | 1 | 1 | 1 | 2.2 | 2.2 |
Filtering area(m2) | 0.25 | 0.25 | 0.25 | 0.25 | 0.3 | 0.3 |
Residue exhausting diameter(mm) | 800 | 800 | 800 | 800 | 1000 | 1000 |
Steam cost(kg/h) | 285 | 346 | 570 | 660 | 718 | 903 |
Water cost(t/h) | 2.1 | 2.5 | 4.2 | 4.5 | 5.5 | 6.7 |
Heating steam orifice(mm) | 32 | 32 | 40 | 40 | 50 | 50 |
Gas exhausting orifice(mm) | 100 | 100 | 125 | 125 | 150 | 150 |
Cooling water pipe atifice(mm) | 40 | 40 | 50 | 50 | 50 | 65 |
Motor power(KW) | 2 | 3 | 4 | 5.5 | 5.5 | 7.5 |
Agitating speed(r/min) | 24 | 24 | 24 | 36 | 36 | 36 |
Note:Customers' drawings and requirements available, OEM avealiable.
