TQ-Z Series Multi-functional Extracting Tank

Name: TQ-Z Series Multi-functional Extracting Tank
Brand: Jufeng
SKU: 141480728
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Jufeng

Model Number:

TQ-Z

Jiangsu Jufeng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Jufeng

Model Number TQ-Z

Stainless steel tank
Usage: The equipment serves as normal pressure, temperature dip, thermal influx and compel lent cycle, infiltration and extraction of aroma oil and reclaim of organic solvent, etc. in such industries as pharmacy, vegetable, animal, food and chemistry, especially effective in the case of dynamic extraction or inverse extraction, featuring short time of extraction and high pharmacy content.

The matching facilities including:
Collecting machine, condenser, cooler, filter, oil-water separator and cylinder operating plate.

Model and specification	TQ-Z-1	TQ-Z-2	TQ-Z-3	TQ-Z-4	TQ-Z-6	TQ-Z-8
Volume(L)	1200	2300	3200	4300	6300	8500
Designed pressure inside pot(Mpa)	0.09
Jacket design pressure(Mpa)	0.3
Material imputting diameter(mm)	400	400	400	500	500	500
Heating area(m²)	3	4.7	6.8	8	10	12
Condensing area(m²)	4	5.4	8	10	10	15
Cooling area(m²)	1	1	1	1	2.2	2.2
Filtering area(m²)	0.25	0.25	0.25	0.25	0.3	0.3
Residue exhausting diameter(mm)	800	800	800	800	1000	1000
Steam cost(kg/h)	285	346	570	660	718	903
Water cost(t/h)	2.1	2.5	4.2	4.5	5.5	6.7
Heating steam orifice(mm)	32	32	40	40	50	50
Gas exhausting orifice(mm)	100	100	125	125	150	150
Cooling water pipe atifice(mm)	40	40	50	50	50	65
Motor power(KW)	2	3	4	5.5	5.5	7.5
Agitating speed(r/min)	24	24	24	36	36	36
