TQ-Z Plant Extraction Machine

TQ-Z Plant Extraction Machine thumbnail-1
TQ-Z Plant Extraction Machine photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
JFENG
Contact Supplier Request Quote Chat Now
Jiangsu Jufeng Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Lianyungang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name JFENG
Model Number TQ-Z-1
Processing Types Other, food,vegetable,Chinese herb,plant
Voltage 380
Power(W) 2000
Certification ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas





Product Description



TQ-Z chinese herb extraction machine
Model and specification TQ-Z-1 TQ-Z-2 TQ-Z-3   TQ-Z-4
 TQ-Z-6
 		   TQ-Z-8
Volume    1200   2300  3200  4300  6300   8500

Designed pressure inside pot(MPa)

                                          0.09
Jacket design pressure(MPa)                                           0.3

Material imputting diameter(mm)

  400  400  400  500  500  500
heating area  3  4.7  6.8  8  10  12
condensing area   4  5.4  8  10  10  15
Cooling area   1  1  1  1  2.2  2.2
Filtering area  0.25  0.25  0.25  0.25  0.30  0.30
Residue exhausting diameter(mm)  800  800  800  800  1000  1000
Steam cost(kg/h)  285  346  570  660  718  903
Water cost(t/h)  2.1  2.5  4.2  4.5  5.5  6.7
Heating steam orfice(mm)  32  32  40  40  50  50
Gas exhausting orfice(mm)  100  100  125  125  150  150
Cooling waterpipe atifice(mm)  40 40  50  50  50 65
Motor power (KW)  2  3  4  5.5  5.5  7.5
Agitating speed (r/min)  24  24  24  36  36  36
Usage
The equipment serves as normal pressure,temperature dip, thermal influx and compel lent cycle, infiltrationand extraction and extraction of aroma oil and reclaim of organic solvent,etc in such industries as pharmacy,vegetable, animal, food and chemistry , especially effective in the case of dynamic extraction or inverse extraction, featuring short time of extraction and high pharmacy content.
TQ-Z plant extraction machine

 The matching facilities include



     Collecting machine, condenser,cooler, filter, oil-water separator and cylinder operating plate.



Packaging & Shipping



Our Services

 Jfeng enterprise is a professional diversfied machinery manufacturer integrating design,  development,manufacturing,engineering installation,after-sales service,etc. The company took the lead among the industry in obtaining the National D-class "special equipment manufacturing license" and ISO9001:2000 international quality system certification.





Company Information

Wenzhou Longwan Xinghuo Food Engineering Machinery Factory was founded in April 1995 with its registered trademark of “Xinhuo Enterprise”. It is mainly engaged in food, dairy, fruit juice, beverage machinery whole-set equipment. During its development, the enterprise has won recognition and trust from many small and medium-sized enterprises such as Beijing Huiyuan Group, Shanxi Wanrong Huiyuan, Anhui Dangshan Huiyuan, Hebei Hengshui Huiyuan, Harbin Huiyuan and other more than 40 member enterprises of Huiyuan Group, Zhejiang Kuaihuolin Food Co., Ltd., Lanxi Kuaihuolin Food Beverage Group, SDIC Zhonglu Fruit Juice Co., Ltd., Haisheng Fresh Fruit Juice Co., Ltd., Hengsheng Fruit Co., Ltd., Wangyunhong Fruit Co., Ltd., Hubei Lishizhen Pharmaceutical Group, Wuhan Jianmin Group, Gansu Medicinal Alkaloid Factory, Tianjin Shiji Tianlong Pharmaceutical Co., Ltd., Hunan Jiuzhitang Pharmaceutical Co., Ltd., Hunan Qianjin Pharmaceutical Co., Ltd., Etc.

With the development of market demands and the improvement of production technology, the company is gradually increasing its business range, which includes fruit juice, beverage, dairy turn-key projects, biological engineering, pharmaceutical engineering, sanitary fluid fittings, etc. In August 2007, it was successfully renamed as Zhejiang Jufeng Machinery Factory and its trademark was changed into “Jufeng”. With the expansion of production scale, the company invested RMB 40 million Yuan in 2009 in establishing Jiangsu Jufeng Machinery Co., Ltd. That took an area of 35 Mu



Under the long-term objective of " serving the world ", the company has introduced a large contingent

of high-quality and well-trained professional talents, including 2 senior engineers of professor title,

6 senior engineers, and 20 technicians of intermediate titles.

The company has applied advanced management system to effectively organize,coordinate,standaraize

and control various resources of the company and the whole production and management process.Morever,

it has constantly made technical exchanges with relevant scientific research institutes and experienced experts

in the industry to continuously promote the scientific research and innovation ability, striving to further improve

Jufeng advantageous strength through "   advantageous talents,advantageous managemnet, advantageous technology and advantageous equipment"
