TQ Series Multi-functional Extracting Tank

US$ 2,000 - 6,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Contact Supplier Request Quote Chat Now

Jiangsu Jufeng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Specifications

Name:Multi-functional Extracting Tank
stainless steel SUS304,SUS316L

This equipment is suitable for extracting the effective component and essential oil from Chinese herbals and other botanical in pharmaceutical, foodstuff and chemical industry.

Feature:

1.This equipment mainly is consist of extracting tank, external circulatingt concentrator and other accessory.It is with compact structure ,simple operation and combining extraction, concentration, solvent recycling together.

2.The whole process is in a airtight condition and finish extraction and concentration at one time completely.It can process big quantity material and with less slolvent ,short extracting time.

3.The temperature can be controlled freely in 48-100°C, so it can realize low temperature extraction,hot backflow, low temperature backflow and low temperature concentration.It is especially suitable for some heat-sensitivity material and can configure with the PLC control system.

Parameter

Model	0.5m3	1m3	2m3	3m3	4m3	6m3	8m3	10m3
total volume(L)	650	1200	2300	3300	4300	6400	8600	11000
pressure in extractor (Mpa)	<0.1
Pressure in jacket(Mpa)	<0.3
compressed air pressure (Mpa)	0.6-0.7
diameter of filling capacity (mm)	350	400	400	400	400	450	500	500
diameter of discharge door(mm)	600	800	800	800	800	1000	1000	1000
heat area(m2)	2.7	3.6	5	6.5	7.5	10	12	14
Condenser area(m2)	3	4	5	8	6	8	12	15
cool area (m2)	0.5	0.5	1	1	1	1.5	1.6	1.5
filter area(m2)	0.25	0.25	0.25	0.25	0.35	0.5	0.5	0.8
mix speed(r/min)	25
mixer power (kw)	1.1	2.2	3	4	5.5	7.5	7.5	11
