low price and professional techniciants plastic tire with high oil output rate
- 20 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Condition: | New | Type: | Tire Machine | Tire Machine Type: | Tire Recycling Machine |
Place of Origin: | Henan, China | Brand Name: | DOING | Model Number: | DY-10 |
Voltage: | 220V, 380V | Power(W): | 5.5KW | Dimension(L*W*H): | 24*13*6 |
Weight: | 25-45TON | Certification: | CE,ISO,SGS | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. reliable quality machine2. Q345 R steel
3. warranty:1 year
4. CE,ISO9001
5. 48-55% oil
low price and professional techniciants tire with high oil output rate
Why this project is so popular and how to operate this machine?
Because it is green technology (pyrolysis and distillation) recycling waste to oil resourses.
It is absolutely environmental friendly and create great profits for you. We have successfully installed more than 60 sets machine in different country, India, Iran, Pakistan, Poland, Macedonia, Romania, Turkey, Albania, Malaysia, Mexico etc. Any interests please feel to contact us.
What can you get from this machine?
Take one batch 10t waste tyre pyrolysis plant for example:
Total Output:
1. Crude oil: 45%*10t=4.5t
2. Carbon black: 35%*10t=3.5t
3. Steel wire: 13%*10t=1.3t
No. | Item | Cost of Per Batch |
1 | 10 tons of waste tires | 10T×USD 236/T=USD2360 |
2 | 0.4 tons of coal | 0.4T×USD126 /T=USD50.4 |
3 | Water and electricity | 200×USD0.16=USD32 |
4 | Workers Salary | 4×USD16=USD64 |
5 | Total Cost | USD2506.4 |
NO. | Item | Income |
1 | Crude Oil | 10T×45%×USD709=USD3190.5 |
2 | Carbon Black | 10T×35%×USD82=USD287 |
3 | Steel Wire | 10T×13%×USD34=USD450 |
4 | Gross Profit | USD3927.5 |
5 | Daily Net Profit | USD3927.5-USD2506.4=USD1421.1 |
6 | Monthly Net Profit | USD1421.1×25=USD35527.5 |
7 | Yearly Net Profit | USD35527.5×10=USD 355275 |
How to operate this machine?
1) feed the raw material into furnace automatically or manually, then seal the feed inlet system
2) heat the reactor by burning the fuel material(coal,or wood,or natural gas ,oil ) in the combustion system
the reactor will slowly become heat ,when the temperature reach around 250 degree celsius, the oil gas will be formed
3) After processed by our technology, the oil gas will go to cooling system for cold liquid oil
the gas which can not become liquid under normal pressure , will be desinged to go back to combustion system through safety device instead of the fuel material to burn the reactor, which is environmental friendly and can save you much energy
4)After finished oil produce ,the temperature of reactor will be down,while,carbon black can be discharged automatically
5) when the temperature fall down to 100 degree celsius,worker could opened the door of reactor to discharge of steel wire
6) Then can start to another batch working
Technical Detail
This is a batch process system.
The waste tyres are fed into the reactor vessel and heated under controlled conditions of temperature and pressure.
The process will bring about molecular restructuring of the rubber under the pyrolysis process as the result; furnace oil in gaseous form is produced along with other gases.
These vaporized gases are passed through heat exchanges, where in the furnace oil is condensed into liquid form.
During the process, carbon black and steel are also generated.
The heat exchanger uses coolant water, as a condensing medium and this water is re-circulated through process.
After-sales service
Installation and Training: We will send one technicians for each set of machine to your company within 10 days when the machine arrives to your factory. The technicians will be charge of guiding your installation, testing the machine and training your workers. The installation period shall be 30 days. You shall pay salary for the technician with 50USD per day and also the round-trip ticket and accommodation.
As we all know, this is a special field, high profit and high risk. So, when you choose a supplier, security will be the most important thing.Except security, technology, quality and oil refining experience are also very important. Since this is a new field, so, no exact rules. In this way, experices and technology will be the key point. As for the quality, it should be worth of your cost.
