manufacturer of cintinuous waste tyre pyrolysis plant and recycling machine to oil
- 30 Set / Sets per Month
- lianyungang port
- T/T
- complete set of pelletizer flue gas treating machine
- one-stop pelletizer flue gas treating machine
- Best performance pelletizer flue gas treating machine
- stainless steel pelletizer flue gas treating machine
- Portable pelletizer flue gas treating machine
- complete set of organic waste processing equipment
Product Details
Condition: | New | Automatic Grade: | Automatic | Place of Origin: | Henan, China |
Brand Name: | XHZT | Model Number: | XHZT-2260 | Voltage: | 380V |
Power(W): | 20KW | Dimension(L*W*H): | 2200*6000*16 | Weight: | 28T |
Certification: | CE,ISO,LVD,EMC | Warranty: | 12 month | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
manufacturer of cintinuous waste tyre pyrolysis plant and recycling machine to oil1 high oil yield
2 pollution free
2014New Technology Continuous Used Tyres Pyrolysis Device Recycling Machine
Introduction of Waste Tire Pyrolysis Recycling Machine | |
Reactor | 1. Made by Q345 boiler plate. 2. Auto-welding both inside and outside 3. With rock wool insulation board |
Auto-feeder | 1. 50 ton hydraulic pressure 2. Can feed all types of materials 3. Save labor and save time
|
Catalyst chamber | 1. Improve oil yield and oil quality 2. Reduce the speed of oil gas so that it can be better cooled |
Oil-water separator | 1. Separate oil and water 2. Collect heavy oil 3. Water sealing design keep safety |
Condenser | 1. The oil gas is cooled separately by small pipes inside condenser 2. Light oil is collected here |
Vacuum device | Keep machine running under normal pressure |
Anti-back fire device | 1. Recycle residual gas to furnace as fuel 2. Water sealing design prevent tempering |
Dust removal device | Dispose of flue gas caused by using coal, wood, oil or natural gas. |
Feathers of Waste Tire Pyrolysis Recycling Machines:
1. You just need preheat at the first time when the machine start producing. And then the
machine can produce lasting for 20days without stop. Because it can use the waste gas to
heat the chamber, no need other energy.
2. The most capacity can reach 30T/D, much bigger than other kind of plant. It is fully-automatic and fully –continuous.
3. New design of vertical condensers .you can get high oil yield, good oil quality, high profit.
4. Low requirement on the raw materials, no need tiny granule, 10cm pieces acceptable for
smooth running.
5. With CE.LVD.ISO.EMC Certificate
The Technical Parameter
NO. | ITEM | Technical Parameter |
1 | Suitable Raw Materials<=5cm | Small pieces of Waste tyre,rubber,waste plastic<=10cm |
2 | Operating Mode | Fully Continuous Opreation |
3 | Structure | Horizontal Type |
4 |
Loading and discharging | Fully automatic feeding and discharging under high temperature at the same time |
5 | Capacity(24h) | 8-20Mt |
6 | Work Pressure | Slightly Negative Pressure |
7 | Oil Yield of tyres | 40%-45% |
8 | Reactor Rotation Speed | 1R/M |
9 | Power | 50-60kw/h |
10 | Cooling Method | Cycle water |
11 | Type of Drive | Sprocket Wheel |
12 | Heating Method | Hot Air |
13 | NoisedB(A) | <=85 |
14 | Main Reactor Weight(Mt) | 15-18Mt |
15 | Total Weight(Mt) | 30—40Mt |
16 | Installation Space Required | 60m*30m |
17 | Manpower | 2/shift |
18 | Shipment | 1*40FR+3~4 HC |
19 | Delivery time | <=70Days |
about our company
a> our company has two factories, one is in Qingdao city where u could see the working plants there; the other is in Shangqiu city where u could see how to make the pyrolysis and distillation equipments.
b> our engineer: Jianhua, zhou is our chief engineer. he has got 6 patents in the different devices of the pyrolysis equipment. he has been engaged in this plants for almost 20 years. and also he is the chief engineer in a South-Korea company.
Zhihua, Wang is another best engineer, he has been engaged in this equipment from 2003, he has been to many cities in China and many countries for installation. he is full of experience in installation.
Yuanzhi, Sha is another best engineer, he has been engaged in this plants for almost 25yeas. he has improved our technology and developed the equipments to make it more practical for our customer
about the clients around the world
Southeast Asia( for disposing plastic and used tires)
USA ( for disposing plastic and tires)
Italy ( for disposing plastic)
Brazil ( for disposing plastic)
Saudi ( for oil sludge)
China (for disposing mill paper, plastic, used tires, medical waste)
South-Korea( for disposing plastic)
Poland(for waste tyre)
Turkey(for scrap tyre)
Indonesia(for oil sludge)
Thailand(for waste tyre)
Philippine(for full tyres)
Iran(for waste tyres)
Malaysia(for waste tyres)
India ( for disposing used tires)
