1. Plant parameter
1 |
The raw materials: |
Fuel oil /waste machine oil / transformer oil/waste lube/pyrolysis oil |
2 |
Out put |
Base oil |
3 |
Daily capacity: |
20 ton /day |
4 |
The size of reactor(D*L) |
2200*6000 mm |
6. |
Reactor material |
Q345R |
7. |
Final oil out rate |
75-85 % |
8. |
Feeding way |
continuous |
9 |
Slag out |
Auto continuous |
10 |
Working area |
500-600 square meters |
11 |
Cooling way |
By water |
12. |
Heating way |
Direct/indirect |
13 |
Working presure |
Normal/slightly negative |
14 |
Effective working temperature |
180-400℃ |
15 |
Power |
36.5 kw |
16 |
voltage |
220v/380v |
17 |
Fuel to heating |
Coal wood, gas oil, etc |
18 |
type |
Pollution free |
19. |
certificate |
CE.ISO |
2. Work flow:
Pump crude oil or mazut oil or waste engine oil in distillation reactor,By heating and chemical extracted nerve , separate diesel and gasoline in different temperature
in this way, we can recycle or refining curde oil or waste oil to good light oil .
3.Plant features:
A. one machine can be used for multiple material.
the machine can be used for waste oil,have oil, furnace oil ,crude oil etc
B. Newest tech
saving fuel energy, waste gas can be reused again, preheating system can use
emmission smoke to heating raw oil
C .100% Pollution free.
3-level dedust system, make sure only little white water steam come into air from chimney
D. Good after sale service and good plant quality
we will offer 2 year guarantee period for our machine.
and enginer oversea service is available
E, High oil rate out put make sure users get more profit
3. Major parts:
4. Other specification for your chose
NO. |
Model |
Raw material |
capacity |
1 |
XHZT-DE05 |
Used engine oil ,tyre oil ,plastic oil,crude oil
|
5 MT |
2 |
XHZT-DE10 |
10 MT |
|
3 |
XHZT-DE15 |
15MT |
|
4 |
XHZT-DE20 |
20 MT |
|
5 |
XHZT-DE25 |
25 MT |
|
6 |
XHZT-DE30 |
30 MT |
5.Oil Parameters:
|
Petrol |
Chemical formula |
C6—C12 |
Oxengy content (%) |
|
Hydrogen content (%) |
|
Carbon content(%) |
|
Density(20°Ckg/L) |
0.75 |
Boiling point(°C) |
70-97 |
Latent heat ML/kg) |
|
Kenematic viscosity (20°C)(Pas:10-3) |
0.1 |
Octane values(RON) |
82 |
Geotherm value HL(MJ/L)26.778 |
|
Theoretical gas mixture heat value (ML/kg) |
|
kindling temperature(°C) |
330 |
Theoretical air-fuel rato (kg/kg) |
|
6. The meaning of our plant
Our facatory establish in 2010, and before 2010 our enginer and our workers works in other factory woking in this plant . so our real experiance should be more than 8 years.
during these years we are reasearch and test how to making the waste oil to avaualbe .
especailly go with by the oil exploration, more and more mazut oil be produced ,
if we not treat them, they will pollution the invironment, since their large quantity.
and another thing, now energy short also a problem.
so if we can change these mazut oil or residule oil to diesel ,it will be very good thing .
one more thing, along with the developemtn of pyrolysis plant using,
more and more tires changed to fuel oil, but these fuel oil can not be directly use to engine as diesel or gasoline,
so the disitllation plant solve this problem.
in one words, our technology treat waste to diesel and bring the words new engergy . but not pollution .so our planst is green and profit plant for our users .
You are welcome to us for order our plants.
