Horizontal diatomite filter portable, wine filtering press
- 30 Set / Sets per Month
- Shanghai Qingdao Tianjin Port.
- T/T L/C D/P D/A Credit Card PayPal
- Plastic Packaging Film Heat Seal Tester/Laboratory Heat Sealer / five points heat seal tester
- (ASTM D882) Electronic Tensile measurement
- (ASTM D882) tensile test
- Electronic Tensile Strength Testing Machine desktop tensile testing machine
- High quality cof tester (GM-4)
- GHH Multifunctional Universal Tensile Tester for peeling, bonding, sealing puncture and compression test.
Product Details
Condition: | New | Type: | Other, Filter press | Product Type: | Other |
Place of Origin: | Henan, China | Brand Name: | Toper | Model Number: | WK |
Voltage: | 380 v | Power(W): | 1.5 Kw | Weight: | 250 Kg |
Dimension(L*W*H): | Optional | Certification: | ISO9001;2008&CE | Warranty: | 18 month |
After-sales Service Provided: | Overseas third-party support available |
Product Description
1. filter plate filter made of AISI316L, the rest are AISI304, automatic mechanical polishing inside and outside surfaces of the tank, and all parts in contact with the liquid in line with food-grade sanitary requirements.
2, taking into account the unique plate design, self-supporting, filters smooth, easy to clean.
3. The filter formed on the soil filter discs, so that the whole loop filter in a sealed state.
4. Add the diaphragm metering pumps, according to the filtrate turbidity be, adjusting the amount of diatomaceous earth filter aid.
5. placed outside the main canister residue filtration system, do not need compressed air, infusion pumps with their own power, a very short time, complete the remaining liquid filtration main filter tank.
6. The filter-cake removal, filter disc cleaning automatically.
7. Road entrance before filtration pressure power, do not need pressurization equipment, strong pressure stability.
Working principle of the wine filtering press:
In a sealed stainless steel container, bottom horizontal stainless steel filter disc, the upper disc is stainless Steel strainer, the lower is the stainless steel support plate, the middle is a liquid collection chamber.
When filtered through Celite first pre-coated, so that a layer of diatomaceous earth coating is formed on the plate, the liquid to be filtered at the pump pressure, by pre-coating and into the collection chamber, the particles and the polymer is closure in pre-coating of a clear liquid into the collection chamber, through the central axis out of the container.
Photos of the wine filtering press:
Model | Overall dimension(mm) | Filter area(M2) | Quantity of filter disc(Pc) | Valve size | Theoreical Flow (base on white spitit) | Working pressure(Mpa) | Pump |
WK500-A | 2450x750x850 | 15.9 | 38 | Dg32 | 13-15t/h | ≤0.3 | YL20-25 |
WK500-B | 1950x750x850 | 8.9 | 20 | Dg32 | 8-10t/h | ≤0.3 | YL20-25 |
WK400-A | 2350x680x800 | 9.8 | 38 | Dg32 | 9-12t/h | ≤0.3 | YL10-25 |
WK400-I | 1840x680x800 | 5.1 | 20 | Dg32 | 6-8t/h | ≤0.3 | YL5-25 |
WK330-II | 1700x600x750 | 3.4 | 20 | Dg32 | 3-5t/h | ≤0.3 | YL5-25 |
WK330-III | 1600x600x750 | 2.5 | 15 | Dg32 | 2-4t/h | ≤0.3 | YL5-25 |
WK250 | 1100x350x450 | 2 | 20 | Dg32 | 1-3t/h | ≤0.2 | YL3-20 |
WK220 | 900x300x400 | 1 | 15 | Dg32 | 1-2t/h | ≤0.2 | YL3-20 |
Since 2006,Our equipment has been exported to many countries all over the world such as India, Pakistan, Sri Lanka, Bangladesh, Indonesia, Philippines, Malaysia, Vietnam, Singapore, Turkey, Israel, Burma, Jordan, Yemen, Iran, Iraq, Afghanistan, Syria, Kuwait, Kazakhstan, Qatar, Korea, Azerbaijan, The UAE, Bhutan, Thailand, Lebanon, Bahrain, Egypt, Libya, Ethiopia, Kenya, Somalia, Tanzania, Liberia, Ivory Coast, Ghana, Nigeria, Cameroon, Chad, Guinea, Zambia, Zimbabwe, Malawi, Congo, Gabon, Angola, Mozambique, Botswana, Namibia, South Africa, Argentina, Bahamas, Bolivia, Brazil, Canada, Columbia, Chile, Cuba, Venezuela, Ecuador, Guatemala, Guyana, Honduras, Haiti, Mexico, Peru, Uruguay, Paraguay, Surinam, Australia, Russia etc.
Our manufacturing base of filter equipment mainly produce full automatic or semi-automatic membrane filter press, recessed filter press, belt filter press, centrifuge, etc. All these products are widely used in mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, food, alcohol, inorganic salt, coal washing, and waste water processing industry.
Our products has passed ISO9001 International Quality Management System Certification and is exported to America, Canada, Chile, Bolivia, Indonesia, Malaysia, Israel, Iran, Egypt, Turkey, Romania, Sweden, Finland, etc. about more than 50 countries and area. We have won good reputation depends on our best qualified products and after-sales service. Warmly welcome new and old friends all over the world to come our company for good cooperation with each other!
FILTER PRESS SERIES:
Filter presses can be divided into plate and frame type and are used for solidliquid separation of various suspending liquid in intermittent pressure filtration. Filter plates are pressed by pressing devices and suspending liquid is pumped into the filter chamber. Solid particles and separated through filter cloth. The products are simple in structure but good in separating effects, convenient in use, and widely applicable to mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, foodstuff, alcohol, inorganic salt, coal washing, dyestuff and sewage treatment industries.
All of Toper's products:
1. Program-controlled automatic filter press
2. Membrane filter press
3. Hydraulic compress filter press
4. Mechanical compress filter press
5. Jack filter press
6. Cast iron plate and frame/chamber filter press
7. Stainless steel plate and frame filter press
8. Round plate filter press
9. Cotton cake filter press
10. Cardboard filter press
11. DY belt filter press
12. DYX high pressure belt filter press
13. DNY rotary drum thickning/dehydrating belt filter press
14. Triple-belt thickning and dehydrating filter press
15. SS type three-foot upper discharge centrifuge
16. SD type three-foot and filter bag hoist discharge centrifuge
17. PD type filter bag hoist discharge centrifuge
18. Centrifuge of up discharge, three foot, clean series SSB, SB
19. SX type manual top discharge centrifuge
20. PS type manual top discharge centrifuge
21. SGZ type automatic scraper bottom discharge centrifuge
22. PGZ type scarper bottom discharge centrifuge
23. LW series decanter centrifuge
24. Tubular centrifuge
25. Multi-layer stainless steel frame filter
26. Bag filter
27. Diatomite filter
28. Filter late
29. Filter cloth
30. Vacuum disc filter
Horizontal diatomite filter portable, wine filtering press
Horizontal diatomite filter portable, wine filtering press
Horizontal diatomite filter portable, wine filtering press
