Serological centrifuge used in laboratory for testing and experiments,high speed tubular centrifuge machine
- Brief introduction of the blood centrifuge machine
-
Main Purposes
The blood separator is one kind of tubular separator. This machine is the improved one on the base of the original separator and through experiment again and again.It can be extensively used in separating blood plasma and cell of people, pig, cow, sheep and chicken etc.
-
Product Description
Dehydrated bovine plasma is manufactured with fresh blood obtained under sanitary conditions from animals selected both before and after slaughter, exclusively in officially controlled plants. The dehydration system used during the process is called spray atomization and involves spraying plasma in countercurrent to a flow of hot dry air, leading to its dehydration.
This drying system yields a highly nutritional product since it avoids destroying essential amino acids that are senitive to heat.
-
Main Features
The main feature of it is the high yield and the rate of broken blood cell can be reduced to the lowest extent. The contact part between the separator and material is made of stainless steel which can meet the requirement of GMP in medicine making industry.
- Description of the tubular centrifuge :
- The high speed tubular centrifuge is mainly used in liquid-solid separation, liquid-liquid-solid separation in bio-pharmacy, beverage, chemical industry. It is an ideal separation equipment by centrifuging, especially for those feeding with little gravity difference, and small dimension in diameter.
- Strong in separation, simple in structure, convenient in operation and maintenance, low in consuming power, small in ground, high in speed ,strong in separation factor, small in noise, adaptive in material with high or low temperature.
-
The tubular centrifuge has two types according to the stipulation of the national specialized standard:
GF separation type: It is mainly used for separating all kinds of emulsion
which is very difficult to be separated in separation industry, especially suitable for liquid-liquid separation with every small gravity differential of the two phases and separation of liquid-liquid-solid phases contained a little impurity.
GQ clarification type: It is mainly used for separating all kinds of suspensiondifficult to be separated, especially suitable for separation of solid-liquid suspension with light concentration, fine particles and very small differential gravity of the two phases
-
Working principle and Machine Structure
The separator consists of machine body, driving part, bowl, liquid collecting pan and liquid-in bearing seat etc.
The material is sprayed onto the bowl from the inlet on the bottom and strong centrifuge force is formed when the bowl rotates with the material and that makes the material flow upper along the wall of the bowl and then separated because of the different gravity by the centrifuge force.
GF-for separation: Heavy liquid forms outer ring and light liquid forms inner ring. They flow to the top of the bowl and discharge from their respective outlet. And the little solid is settled on the wall of the bowl and discharged manually after the machine stops.
GQ-for clarification: Heavy solid is deposited on the inner wall of the bowl,and forms the sludge. And it will be discharged by manual after the machine stops. The clear liquid flows out of outlet from the top of the bowl.
The motor connect with the big pulley and delivery the power to the spindle through the belt, tensioner and small pulley and rotate with the bowl in high-speed as the clockwise
Technical parameters of the tubular centrifuge :
| Model | drum | nozzle diameter (mm) | Productivity (water flow) (kg/h) | Power(kw) | weight (kg) | ||||
| Inner diameter (mm) | Height (mm) | volume (L) | Rotary speed (r/min) | separation factor | |||||
| GF45 | 45 | 280 | 0.45 | 50000 | 60000 | 2,3 | 150 | 0.75 | 90 |
| GF75 | 75 | 450 | 2.7 | 21000 | 22500 | 4,6 | 500 | 1.5 | 300 |
| GF105 | 105 | 730 | 6 | 19000 | 21000 | 6,8 | 1500 | 2.2 | 480 |
| GF125 | 125 | 730 | 7.4 | 16000 | 18000 | 5,8,9 | 2000 | 3.0 | 520 |
| GF150 | 142 | 730 | 10 | 15000 | 17000 | 8,10,12 | 3000 | 3.0 | 550 |
Tubular Centrifuge Principle:
Different model tubular centrifuge from Toper for sale
We provide you reliable and fast package and variety kinds of transportation way to insure you get the goods in time and safely.
1.We have professional person on line to advise you the most suitable type of machie according to your requirement.
2.Provide you comprehensive.easy-understanding and detail information and technical data about the machie you interested;solve your confusions or questions about the machine
3.Arrange the schedule if you pay a visit to our factory.
4.Our technical engineer can also to your country guide for the installation ,operation ,solve problems and so on if required.
Our manufacturing base of filter equipment mainly produce full automatic or semi-automatic membrane filter press, recessed filter press, belt filter press, centrifuge, etc. All these products are widely used in mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, food, alcohol, inorganic salt, coal washing, and waste water processing industry.
Our products has passed ISO9001 International Quality Management System Certification and is exported to America, Canada, Chile, Bolivia, Indonesia, Malaysia, Israel, Iran, Egypt, Turkey, Romania, Sweden, Finland, etc. about more than 50 countries and area. We have won good reputation depends on our best qualified products and after-sales service. Warmly welcome new and old friends all over the world to come our company for good cooperation with each other!
FILTER PRESS SERIES:
Filter presses can be divided into plate and frame type and are used for solidliquid separation of
various suspending liquid in intermittent pressure filtration. Filter plates are pressed by pressing
devices and suspending liquid is pumped into the filter chamber. Solid particles and separated
through filter cloth.
The products are simple in structure but good in separating effects, convenient in use, and widely
applicable to mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing,
paper making, foodstuff, alcohol, inorganic salt, coal washing, dyestuff and sewage treatment
industries.
All of our products:
1. Program-controlled automatic filter press
2. Membrane filter press
3. Hydraulic compress filter press
4. Mechanical compress filter press
5. Jack filter press
6. Cast iron plate and frame/chamber filter press
7. Stainless steel plate and frame filter press
8. Round plate filter press
9. Cotton cake filter press
10. Cardboard filter press
11. DY belt filter press
12. DYX high pressure belt filter press
13. DNY rotary drum thickning/dehydrating belt filter press
14. Triple-belt thickning and dehydrating filter press
15. SS type three-foot upper discharge centrifuge
16. SD type three-foot and filter bag hoist discharge centrifuge
17. PD type filter bag hoist discharge centrifuge
18. Centrifuge of up discharge, three foot, clean series SSB, SB
19. SX type manual top discharge centrifuge
20. PS type manual top discharge centrifuge
21. SGZ type automatic scraper bottom discharge centrifuge
22. PGZ type scarper bottom discharge centrifuge
23. LW series decanter centrifuge
24. Tubular centrifuge
25. Multi-layer stainless steel frame filter
26. Bag filter
27. Diatomite filter
28. Filter late
29. Filter cloth
30. Vacuum disc filter
