TDP5 Single Punch Tablet Presser with 1pcs normal mould
Description
Place of Origin: Guangdong China (Mainland)
Production Capacity (pcs/h): 4000
Type: Single Punch
Brand Name: OEM
Model Number: TDP5
Type: Tablet Pressing Machine
Mould Die: 1pcs round mould die with logo .When you place the order , please offer us the mould size you need .
Application
Tablet Voltage: 110V or 220V or 240v or 380v or any Voltage customized
Max.Main Pressure (kn): 50
Max.Pressure Diameter(mm): 20
Max.Filling Depth(mm): 16
Max.Tablet Thickness(mm): 6
Max. Production capacity (p/h): 3800
Motor (KW): 0.75
Outside size(mm): 700X380X695
Weight (kg): 120
Introduction
The machine is suitable for the industries of Chemical, Foodstuff,Electronic and etc.It is used of pressing medicinal tablets,catalysts,sugar tablets,Calcium tablets,Coffee tablets,Powder Metallurgical,Electronic elements and various tablets of pesticide and fertilizer.etc.in such small-batch production,laboratory and hospital fields.Meanwhile,that machine also can press various abnormity and normal tablet,and press the tablets in two sides with printing as well.
Main Technical Parameters
Material: Metal and Aluminum.
Model:
| TDP-1.5
| TDP-5
| TDP-6
|
Max.Main Pressure (kn)
| 15
| 50
| 60
|
Max.Pressure Diameter(mm)
| 12
| 20
| 25
|
Max.Filling Depth(mm)
| 12
| 16
| 18
|
Max.Tablet Thickness(mm)
| 6
| 6
| 7.5
|
Max. Production capacity (p/h)
| 4500
| 4000
| 3000
|
Motor (KW)
| 0.55
| 0.75
| 1.1
|
Outside size(mm)
| 570×380×630 | 700X380X695 | 700X380X695 |
Weight (kg)
| 90
| 125
| 165
|
