Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > Pharmaceutical Tablet Press Machine ZP-35D

Pharmaceutical Tablet Press Machine ZP-35D

Name: Pharmaceutical Tablet Press Machine ZP-35D
Brand: YASON
SKU: 141472870
Availability: InStock

Shenzhen Yason General Machinery Co., Ltd.

Pharmaceutical Tablet Press Machine ZP-35D thumbnail-1

Pharmaceutical Tablet Press Machine ZP-35D photo-1

US$ 8,000 - 12,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Guangdong, China

Brand Name:

YASON

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen or NingBo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Guangdong, China

Brand Name YASON

Model Number ZP-35D

Type Other, Rotary Tablet Press, ZP35D

Production Capacity 150000pcs/h

Max. Pressure(KN) 80kn

Max. Tablet Thickness(mm) 6mm

Max. Tablet Diameter(mm) 13mm

Voltage 220v or 110v

Power(W) 4KW

Weight 1850KG

Dimension(L*W*H) 980*1240*1690mm

Certification GMP

After-sales Service Provided No overseas service provided

Specifications

1.Available for irregular shape tablets
2.Full SS Body
3.Customized Dies Accepted
4.Meet GMP Standard

ZP-35D AUTOMATIC PRESS PILL MACHINE

Ask the manual and opeation video from us if you need!!!

♦Application♦:

ZP35D/37D/41D rotary press pill machine is a double-pressing type, continuous automatic tablet press for pressing granular raw materials into tablets with different shapes, double color and impressed letters on both sides. It is mainly used in manufacturing piece prescription in pharmaceutical, chemical, foods, electronics industry.
(Note: when manufacturing double color pieces, it not only need to replace components, but also a device for removing and sucking powders which greatly lowers the cost and increases profit.)

♦Main Features♦:

Peripheral casing is closed form which is made of all stainless steel , internal mesa adopt stainless steel material, it can keep the surface glossy and prevent cross contamination and meet GMP requirement.

1) It is equipped with organic glass and visual window, visual tablet state, all of the side plate can turn on and clear up and maintanence is easy.

2) All controller and operating parts are rational layout

3) It is equipped with variable frequency speed control device for electrical control, convenient operation, steady running,it is safe and accurate.

4) It is equipped with overload protection device, when pressure overload, it can stop automaticly.

5) It is the mechanical and electrical integration, has touch key and screen display.

6) Be the leader in trying to use semi-automatic lubrication device and the top of rotary table is epuipped organic glass dust prevention device.

7) Transmission system is sealed on the main tank below, is a safe separation of independent components, also has no cross pollution, and transmission of infiltration in the oil pool, easy to has heat output and also it is wearable.

8) It is equipped with powder absorbing device , can absorb indoor dust .

9) Wearing parts like orbit, feeder, hopper, drive worm, powder taking equipment and it has general structure with ZP33 type product , it is helpful for standardization, generalization and seriation.

♦Warranty♦:

1)Technical Support(24 hours on line trademanager, skype, MSN, mobile).

2)Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)

3)Video for debugging after sent products.

4)Pre-maintance.Quality guarantee for 1 year. Within warranty period, we provice spare parts for replacement free if not man-factor.

5)Welcome send us samples to test on our machine and we will take video for you to confirm.

6)Welcome visit our factory for checking machine and offer training course for your workers.

♦Technical Parameter♦:

Type:ZP35D

Die (sets):35

Max.Pressure (KN):80

Max.Dia.of tablet (mm):13

Max.Depth of fill (mm):15

Thickness of largest tablet (mm):6

Turret Speed (r/min):5-36

Production capacity (pcs/h):150000

Motor power (KW):4

Overall dimensions (mm):980×1240×1690

Net weight (KG):1850

♦Pictures♦:

♦Payment Methods♦

These payments of T/T, L/C, Western Union, MoneyGram,Paypal are accepted. If you have any problem with the payment, please leave a message to us.

♦Logistics♦

DHL, EMS and UPS, Fedex are our choices. If you prefer other reliable shipping company. Please leave a message to us.

♦Tracking Number♦

Tracking number will be informed within 2-3 work days after delivery goods. If you have any problem with it, please leave a message to us.

♦Feedback♦

Any comments, suggestions are accepted. We will be very grateful to your positive footprints left in our company. If you have any problem with our products, please leave a message to us.

♦Refund♦

Any damage or shortage of our goods when you receive your items. Please take some photos for a witness. We will deal with it in 24 hours. Frequently, we will send a new part of items for alternative and heavy-damage, Before refund is accepted, please leave a message to us.
