KP120 Auto Point Apparatus

KP120 Auto Point Apparatus is integrated with photoelectric detection, digital temperature display and other technologies, boasts automatic display of initial and final melts and other functions. In the temperature system, linearly calibrated platinum resistor is used as the detection device, offering efficient and accurate test process and results. The apparatus can be widely used in the chemical industry and medicine research and is essential for the production of medicines, spices, dyes and measurement of other organic crystal substances.





Advanced true color VGA touch screen & simple and easy operation and observation;

8-level temperature rise design is satisfactory for varied temperature rise options;

Wider temperature control scope and higher temperature accuracy

Optimal cooling rate and sample test speed;

Exclusive integral design;

It’s completely in line with pharmacopeia and GLP requirements.





Melting Point range: Room temperature 50°C~400°C

“Initial temperature” setting rate: <=6min (50°C~400°C)

                            <=7.5min (400°C~50°C)

Min. displayed temperature: 0.1 °C

Repeatability: 0.2°C at heating rate of 0.2°C/min

Temperature accuracy: ±0.4°C(<200°C),±0.7°C(<300°C)

Linear heating rate: 0.1°C/min, 0.2°C/min, 0.5°C/min, 1°C/min, 2°C/min, 3°C/min, 4°C/min, 5°C/min   8 level

Standard capillary size: inside dia. 1.0mm, outside dia. 1.4mm

Capacity per batch: 1pcs/batch

Power supply: 220VAC±10%, 50Hz

Power: 150W

Net Weight: 12kg

Dimensions: 455mm×312mm×200mm
