BT600F/2*YZ25 Filling Hose Pump/flow Intelligent Peristaltic Pump

• Color touch screen, making the information more intuitive and the  operation more convenient;
•Intelligence expert operating system can guarantee smooth operation even the operator never used such kind of machine before;
•Motor rotation angle precision control technology, reducing the dispensing errors under traditional time control distribution pattern due to motor slow start;

•Intelligent temperature control technology greatly reduces the operating noise of peristaltic pump;
•It has three kinds of distribution patterns, time dispense mode, fluid volume dispense mode, copying dispense mode. It can meet different needs;
•The function of accumulated distribution of liquid can record total liquid volume;

•Infrared remote control function, it can be non-contact control;
•BT600F dust-proof type of stainless steel case design, suitable for general industrial environments

Specification:

Technical parameters

•Speed range: 0.1 ~ 600 rpm
•Speed resolution: 0.1 rpm, with accuracy 0.2%
•Display: 65535 color LCD + touch screen
•Supply Voltage: AC220V ± 10% 50/60HZ
•Power ratio: < 60W
•Working Environment Temperature: 0 ~ 40 °C Relative humidity <80%
 •Protection level: IP31
•Dimensions: (L × W × H) 223mm×150mm×195mm
•Weight: 5.3kg
