Product Details
Place of Origin: | Shanghai, China | Brand Name: | KINGDAK | Model Number: | KBT102S DT10-18 |
Theory: | Electromagnetic Pump | Structure: | Gear Pump | Usage: | Other, viscosity fluid |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, electricity |
Pressure: | Low Pressure | Application: | Other, pumping a variety of fluids |
Product Description
KBT102S peristaltic pump(speed regulation)
Function and Feature:
•Four-figure digital LED indicator displayers working speed.
• The LED indicator displays the internal control, external control mode.
•mask keypad operation.
• Reversible direction, start/stop and full speed, state memory (power-down memory).
• Easy dispensing function, it realizes the repeat timing quantitative dispensing,
• Speed resolution is above 0.1rpm.
•Stainless steel housing, easy to chean, excellent resistance to the corrosion of the acid, alkali, sodium and the organic Solvents.
• Can drive multi-channels and various types of pump heads.
•The circuit board with conformal coating makes it dust-proof and moisture-proof.
• Super anti-interference feature, wide input voltage range, acceptable for the complex power environment.
• Extermal high-low electrical level controls the start/stop,reversible direction and easy dispensing function, optically coupled isolator; Extermal analog adjusts the rotate speed.
•5V, 12V, 24V level input options.
• RS485 interface, MODBUS protocol is available, easy to connect other equipments.
• Optional footswitch or timer for dispensing fluid.
Technical parameters :
• Flow range :0.0001-480ml/min
• Speed range : 0.1-100rmp
• Speed resolution : 0.1 rmp
• Flow accuracy : <0.5%
• Power supply : AC 220V±10%,50Hz/60Hz(standard),AC110V±10%,50Hz/60Hz(optional)
• Power consumption : <30W
•External control : Input level 5V,12V(standard),24(optional)
•Commumication interface : RS485communication interface, MODBUS protocol is available.
• Operating condition : Temperature 0 ~ 40°C; Relative humidity <80%
• IP garde : IP31
• Dimensions : 224mm*127mm*128mm (L*W*H)
• Weight : 2.7KG
Drive type | Pump head | channel | Tube size(mm) | Flow rate |
(ml/min) | ||||
one channel | ||||
BT102S(304 Stainless case ) | DG6-1(6 rollers) | 1 | Wall 0.8~1,ID ≤3.17 | 0.00016~49 |
DG10-1(10 rollers) | 1 | Wall 0.8~1,ID ≤3.17 | 0.00011~41 | |
DG6-2(6 rollers) | 2 | Wall 0.8~1,ID ≤3.17 | 0.00016~49 | |
DG10-2(10 rollers) | 2 | Wall 0.8~1,ID ≤3.17 | 0.00011~41 | |
DT10-18 | 1 | 13#14#, Wall:0.8~1,ID:≤3.17 | 0.0002~82 | |
DT10-28 | 2 | 13#14#, Wall:0.8~1,ID:≤3.17 | 0.0002~82 | |
YZ15 | 1 | 13#14#16#19#25#17#18# | 0.006~380 | |
YZ25 | 1 | 15#24# | 0.1667~280 | |
YT15 | 1 | 13#14#16#19#25#17#18# | 0.006~570 | |
YT25 | 1 | 15#24#35#36# | 0.006~720 |
The control panel of the peristaltic pump:
