BPZ-6500LC 450L Vertical Type Vacuum Drying Oven

Name: BPZ-6500LC 450L Vertical Type Vacuum Drying Oven
Brand: kingdak
SKU: 141459606
Availability: InStock

Shanghai Kingdak Industries Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

kingdak

Model Number:

BPZ-6500LC

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name kingdak

Model Number BPZ-6500LC

Power Electronic

Usage Universal Testing Machine

Vertical Type Vacuum Drying Oven

Features:

1. Cuboid chamber maximizes the effective cubage. Microprocessor controller for temperature ensures a precise and reliable control.

2. Dual-layer bulletproof toughened glass door ensure absolutely clear observe on objects in chamber.

3. Shutting extent of oven door is adjustable. Closed-cell silicon gasket ensures a high vacuum degree in oven.

4. The chamber is made of stainless steel (or wire-drawing sheet) which allows a durable service and cleaning easily.

5. Store, heating, testing and drying are all in an environment without oxygen or filled with inert gases, which ensures no oxidation.

6. Minimum heating time is over 50% less than that of traditional vacuum drying oven.

Model	BPZ-6500LC	BPZ-6210LC	BPZ-6123LC
Power supply	220V 50HZ
Power	3600W	2060W	2400W
Temperature Range	RT+10 oC ~ 200 oC
Temperature Resolution	0.1 oC
Temperature Fluctuation	+/- 1 oC
Vacuum Degree	133Pa
Chamber Dimension (WDH)	630810845	560600640	500500500
External Dimension (WDH)	79010301855	7208201750	6606401400
Material of Chamber	Stainless steel(1Cr~18Ni9Ti)
Shelves per Chamber (Normal)	4 Piece (Separate Temprature control)	3 Piece (Separate Temprature control)	4 Piece

Model	BPZ-6090LC	BPZ-6063LC	BPZ-6033LC
Power Supply	220V 50HZ
Power	1300W	1770W	1020W
Temperature Range	RT+10 oC ~ 200 oC
Temperature Resolution	0.1 oC
Temperature Fluctuation	+/- 1 oC
Vacuum Degree	133Pa
Chamber Dimension(WDH)	450450450	400400400	320320320
External Dimension (WDH)	6105901350	6005701390	5504901240
Material of Chamber	Stainless steel(1Cr~18Ni9Ti)
Shelves per Chamber (Normal)	2 Pieces(Separate Temprature control)	3 Pieces	2 Pieces
