KGJ-12 top-press Freeze dryer/lyophilizer/vacuum freeze dryer

lyophilizer, vacuum freeze dryer,freeze dryer

Major Characteristics:
∴Imported compressor, high capability of water-capture, low noise;
∴Match the green environmental protection of international standard;
∴Big openings of the cold trap, without coil pipe inside, have pre-freeze
function;
∴ Liquid crystal display, Chinese (English)interface, display drying curve;
∴Small volume , convenient operation;
∴Transparent bell-cap drying room is safe and visual;
∴The pre-cooling shelf can be used as draft tube, so it can accelerate the
speed of drying;
∴ International standard vacuum pump interface may connect varied vacuum
pump;
∴Cold trap and operation panel are all stainless steel, corrosion-resistant and
bright;
∴Communication interface is optional;
∴Valve with nitrogen is optional;
∴Dual-machine cascade refrigeration is optional.The technology is
mature.The temperature is low(apply -80°C device) .

Technical indices:

cold trap temperature: <-55°C,-80°C(is optional)
vacuum degree: <10Pa
 freeze-drying area: 0.08m2
water-capture capability: 3-4Kg/24h
material: 0.8L
material tray: 180mm, 3 layers
12mm xilin bottle: 560
16mm xilin bottle: 285
22mm xilin bottle: 165
power:1070W
dimension: 560×460×(710+430)(mm)
