Help CenterMix Leaching Tank/Mineral Mixing Tank/Mineral Product Agitation Barrel/ Ore Slurrry Agitating Vessel /Economical Agitating Vesse
Related Products
-
Hydro Cyclone Separator/ Hydro Cyclone Cluster/ Mineral Hydro-CycloneUS$ 1 - 9,000MOQ: 1 Set -
Water Separator/Separatory Cone/Separating Cone/Hydraulic Classification BoxUS$ 1 - 9,000MOQ: 1 Set
-
Laboratory Dressing Equipment/ Laboratory Beneficiation Equipment/ Experiment Mineral Equipment/ Experimentation Ore EquipmentUS$ 1 - 9,000MOQ: 1 Set
-
Disk Crusher/ Small Size Disk Crusher/ Laboratory Disk Crusher/Lab Disc Pulverizer/Disc Mill/Sealed Sample Crusher/ Small SizeUS$ 1 - 9,000MOQ: 1 Set
-
Sealed Sample Crusher/ Small Size Sealed Sample Crusher/ Laboratory Sealed Sample Crusher/Grinder For Sample PreparationUS$ 1 - 9,000MOQ: 1 Set
The device is suitable for flotation, re-election, magnetic separation, etc. right concentration of not more than 35% and solid components of the slurry particle size of less than 1 mm to stir, but also can be used for flotation agents and other non-metallic minerals, mixing, so that mine suspended particles and in full access to the Pharmacy, mixing, in order to create conditions for sorting operations.
This series of stirred tank are the following: Agitating tank ,Lifting agitating tank,High concentration agitation tank, High efficiency agitation tank,Specifications of shemical agitation tank
Model |
U nit | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Diameter tank | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Height | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Volume tank | M3
| 0.124 | 0.25 | 0.58 | 1.15 | 2.2 | 4.4 | 11.2 | 19.1 | 46 |
Impeller Diameter | mm | 150 | 240 | 240 | 310 | 400 | 550 | 630 | 700 | 1000 |
Impeller speed | r/min
| 1000 | 530 | 530 | 492 | 320 | 230 | 230 | 210 | 121.6 |
Power | kw | 1.1 | 1.5 | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 | 30 |
Weight | kg | 260 | 320 | 480 | 908 | 1280 | 1760 | 2700 | 18.5 | 8020 |
