Help CenterFlotator With Advanced Technology /High Rate Recovery Flotation/mineral Flotation Series
Related Products
-
Mineral Technology Consultation/Technique Of Preparing/Dressing Machine/Concentrating Machine/Ore Dresser MachineUS$ 100 - 5,500MOQ: 1 Set -
Washing/Classifying Equipment Winning Equipment/Ore Mining Equipment/ Mining Machine Equipment PlantUS$ 1,111 - 5,555MOQ: 1 Set
-
Wet Separator/Water Processing/Washing Equipment/ Tossing /Washing ApparatusUS$ 1,230 - 5,500MOQ: 1 Set
-
Washing Equipment Platinum Gold Lead Zinc/Placer Mining Machine Equipment PlantUS$ 111 - 5,555MOQ: 1 Set
-
Iron Ore Concentration Machine Or Equipment Plant/Gold Ore Concentration Machine Or Equipment Plant/Chromium Ore ConcentratiUS$ 111 - 5,555MOQ: 1 Set
Specifications
1 capacity increases by 12%2 easy to use
3 Low energy consumption
4 large air-absorption capacity
SF flotation machine features:
High quality, precision manufacturing
Larger air-absorption capacity, low power consumption
SF series flotation machine is not only applied to separating the non-ferrous metal, ferrous metals, precious metals, and chemical raw materials, recycling useful minerals, but also applied to selecting the non-metallic minerals such as the coal, fluorite, talc and so on.
Structure and working principle
SF series flotation machine drives the impeller rotate by the V-belt transmission of the motor, and produces the centrifugation effects to form the negative pressure.
This flotation machine can inhale adequate air that to be mixed with the slurry. On the other hand, the mixing pulp is intermixed with the drugs. At the same time, refine the bubble, and make the minerals conglutinate on the bubble, and then float on the surface of the ore pulp, to form the mineralized bubble.
Adjust the height of the flashboard, control the liquid level, and make the useful bubble scrapped by the scraper blade.
Features
SF series flotation machine is the improved product of A-type. It can self-absorb mineral pulp and self-absorb air, its operating room is allocated horizontally. Compared to A-type, it has larger air-absorption capacity, lower power consumption, longer service life of impeller and cover, without need any supplementary equipment, better dressing efficiency.
Technical Parameters
Model | Impeller Diameter(mm) | Impeller Rotational Speed (r/min) | Capacity (m3/min) | Main Motor | Scraper Motor | Size L×W×H | ||
Model | Power (kW) | Model | Power (kW) | |||||
SF-0.15 | 200 | 536 | 0.06-0.18 | Y100-6 | 1.5 | Y80L-4 | 0.55 | 500×500×600 |
SF-0.37 | 296 | 386 | 0.2-0.4 | Y90L-4 | 1.5 | Y80L-4 | 0.55 | 700×700×750 |
SF-1.2 | 450 | 312 | 0.6-1.2 | Y32M-6 | 5.5 | 90S-4 | 1.1 | 1100×1100×1100 |
SF-2.8 | 550 | 268 | 1.5-3.5 | Y180L-6 | 11 | Y100L-6 | 1.5 | 1700×1600×1150 |
SF-4 | 650 | 220 | 2-4 | Y200L-8 | 15 | Y100L-6 | 1.5 | 1850×2050×1200 |
SF-8 | 760 | 191 | 4-8 | Y250M-8 | 30 | Y100L-6 | 1.5 | 2200×2900×1400 |
SF-10 | 760 | 191 | 5-10 | Y250M-8 | 30 | Y100L-6 | 1.5 | 2200×2900×1700 |
JIF-4 | 410 | 305 | 2-5 | Y160L-6 | 11 | Y100L-6 | 1.5 | 1600×2150×1250 |
JIF-8 | 540 | 233 | 4-10 | Y200L2-6 | 22 | Y100L-6 | 1.5 | 2200×2900×1400 |
JIF-10 | 540 | 233 | 4-12 | Y200L2-6 | 22 | Y100L-6 | 1.5 | 2200×2900×1700 |
