Spiral Classifier for Mineral Processing/Mineral Screw Classifier, mineral spiral classifier
- 280 Set / Sets per Month
- Guangzhou
- T/T
You May Like
-
Ore Spiral classifier, China Beneficiation Equipment Ore Spiral Classifier, Simple Structure Spiral Classifier
-
stainless steel jigger, best selling jigger, small XCT jigger , good quality jigger used for gold
-
ore mineral concentration jigger machine/good quality gold mineral jigger
-
Small Size Screening Equipment/ Laboratory Screening Equipment
-
Top Bump Screen/Testing Sieve
-
Standard Sieve/Standard Sieve Shaker
Product Details
| Condition | New | Type | Sprial Separator | |
| Production Capacity | 77-130 t/24h | Place of Origin | Jiangxi, China | |
| Brand Name | oasis | Model Number | 500 | |
| Voltage | 380 V | Power(W) | 1500 | |
| Dimension(L*W*H) | 5480/942/1270 | Weight | 1620 kg | |
| Certification | ISO9001:2008 | Warranty | One year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Spiral classifier is suitable for ore, nonmetal materials were classified, dehydration, to take off the mud and demedium operation.
This series of hierachial machine using solid particle size, shape and density of different and who have different medium in the principle of settling velocity will mineral classification, mainly for the wet grinding system jade grinding units into closed-circuit circulation flow, grinding machine is available through the mineral fine grains of relief and coarse grained return sand two products.
This hierachial machine points are: high dam type single hierachial machine, high dam type double helix sorting machine, sunk type single hierachial machine, sunk type double helix grade machine.
model | spiral | spiral speed |
output | power | external form
| weight | ||
circulating | overflow quantity | Drive | Lift | Kg | ||||
mm | r/min | t/24h | kw | mm | t | |||
300 | 300 | 83-22 | 35-100 | 10-30 | 1.1 | 3840/645/835 | 690 | |
500 | 500 | 8-15 | 54-260 | 77-130 | 1.5 | 5480/942/1270 | 1620 | |
750 | 750 | 2-9 | 100-440 | 31-163 | 3 | 6720/1273/1580 | 2750 | |
1000 | 1000 | 1.6-7.3 | 130-700 | 50-160 | 5.5 | 8000/1576/1934 | 4280 | |
1200 | 1200 | 5-7 | 1140-1370 | 150 | 7.5 | 1.5 | 7970/1703/3080 | 7710 |
1500 | 1500 | 2.5-6 | 1120-2680 | 230 | 11 | 3 | 10196/1976/4080 | 11280 |
2000 | 2000 | 3.6 | 3240-5940 | 400 | 15 | 3 | 40590/4634/4491 | 19930 |
2400 | 2400 | 3.6 | 13600 | 1100 | 22 | 4 | 12710/5436/5690 | 25500 |
