Home > Products > Screen equipment > circular vibrating screen YA series
circular vibrating screen YA series
- 100 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Type | Other, shaker YA | |
| Application | Other, Ore, Ore | Place of Origin | Jiangxi, China | |
| Brand Name | Oasis | Model Number | Refer to specification | |
| Certification | ISO9001:2008 |
Product Description
Specifications
1,easy installation2,high efficiency
3,low cost
4,resonable price
YA, SZZ shaker widely used in mining, smelting, building material, highway, railway, water conservancy and chemical industry and many other sectors of the medium-grained materials, grading, dewatering, de-de or referred mud and operations. This product is the only designated former Ministry of Geology and Mineral production, the implementation of industry standards.
This series of vibrating screen features are: simple structure, reliable operation and maintenance convenience, the user hanging when ordering please specify type and seat type
Model | Screen Layers | Screen Area | Feed size | Capaciry | Opening size | Frequ-ency | Power | Weight |
| Layers |
| mm | t/h | mm | r/min | kw | Kg |
600/1200 | 1 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 350 |
600/1200 | 2 | 1.1 | 40 | 10-20 | 1-15 | 1000 | 2.2 | 360 |
900/1800 | 1 | 1.62 | 60 | 20-25 | 1-25 | 1000 | 2.2 | 550 |
900/1800 | 2 | 1.62 | 60 | 20-30 | 1-25 | 1000 | 3 | 620 |
1250/2500 | 1 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1100 |
1250/2500 | 2 | 3.13 | 100 | 150 | 3-30 | 850 | 5.5 | 1300 |
1500/3000 | 1 | 4.5 | 150 | 220 | 5-40 | 800 | 7.5 | 2100 |
1500/3000 | 2 | 4.5 | 150 | 250 | 5-40 | 800 | 7.5 | 2300 |
1800/4800 | 1 | 7.5 | 200 | 450 | 6-50 | 360 | 15 | 6000 |
1800/4800 | 2 | 7.5 | 200 | 500 | 6-50 | 360 | 15 | 6300 |
