ShiCheng Oasis Mineral Equipment Manufacturing Co., LTD(0086-797-5745599
This model is suitable for screening after the primary ball grinding.
Features
1. Adopt tire coupling and soft connection makes operation smooth
2. Simple structure
3. Be made of good material
4. Easy to repair
5. High capacity and reliability
6. Easy maintenance
Descriptions
Vibrating Screen is widely applied in coal dressing, ore dressing, building material, electricity and chemical industries. It is doing circular movement while at work, and it is of a highly-effective, newly-developed and multilayer machine.With the introduction of eccentric shaft vibration exciter and particular block, the amplitude can be adjustable. Meanwhile, such screen has features of reliable structure, strong excited force, perfect separating efficiency, low noise, long life span, large handling capacity, and durable usage.
(Note: According to different requirements of customers, our company applies vibrating screen with different specifications and vibrating modes.)
Technical Specifications
Model | Layer | Max. Feeding size | Sieve size | capacity | Frequency | Angle (°)
| Motor (W) Power | Dimension | Weight |
SZZ600×1200 | 1 | 40 | 1-25 | 10-20 | 1000 | 15-25 | 2.2 | 1370×890×330 | 340 |
SZZ2600×1200 | 2 | 40 | 1-25 | 10-20 | 1000 | 15-25 | 2.2 | 1370×890×430 | 360 |
SZZ900×1800 | 1 | 40 | 1-25 | 20-25 | 1000 | 15-25 | 2.2 | 2150×1358×575 | 550 |
SZZ2900×1800 | 2 | 40 | 1-25 | 20-30 | 1000 | 15-25 | 3 | 2489×1358×770 | 620 |
SZZ1250×2500 | 1 | 100 | 5-40 | 150 | 850 | 15-20 | 5.5 | 2762×1714×680 | 1100 |
SZZ21250×2500 | 2 | 150 | 5-40 | 150 | 850 | 15-20 | 5.5 | 2702×1714×740 | 1300 |
SZZ1500×3000 | 1 | 100 | 1-40 | 220 | 800 | 15-25 | 7.5 | 3320×1449×787 | 2100 |
Send Inquiry to This Supplier
