gold flotation machine,copper flotation cell,mining separator equipment,fluorite ore machine
The motor drives belt pulleys to make the impeller moving by triangle belt. One is to mix the air and pulp sufficient, the other side is to agitate the pulp with chemical reagents as well as thinning the bubbles. The ore particles stick on the bubbles by the chemical reagents and float to the surface of the pulp and then become the forth and scraped by the scrapper.
Structure and Material,It can be used for non ferrous metals like copper, lead, zinc, molybdenum and gold, black metals and non-metals for roughing and cleaning flotation
Our lab flotation cell have three types:LZFD(Impeller have two speeds),LZFDII(Impeller is frequency conversion stepless speed regulation),LZFDIII(Impeller is frequency conversion stepless speed regulation and ore pulp can adjust temperature control 0-65℃)The lab hanging trough flotator Each model can cheage tank
Model | Volume(m³ | Impeller Dia(mm | Impellerspeed(r/min) | Capacity(m³/h) | Power(kw) | Weight(kg) | |
Impeller | Scraper | ||||||
LZFD0.5L | 0.5Litre | 45 | 2590/2340 | 125g | 90W | 14W | 30 |
LZFD0.75L | 0.75Litre | 45 | 2590/2340 | 187g | 90W | 14W | 30 |
LZFD1L | 1Litre | 55 | 2100/1900 | 250g | 90W | 14W | 30 |
LZFD1.5L | 1.5Litre | 60 | 1910/1750 | 400g | 90W | 14W | 35 |
LZFD3L | 3Litre | 70 | 1890/1708 | 375g | 250W | 14W | 50 |
LZFG5/35 | 0.02-0.14L | 20/26/30 | 1000/1850 | 5-35g | 60W | No | 15 |
LZFG50/100 | 0.2/0.4Litre | 36/48 | 1000/1850 | 50/100g | 60W | No | 16 |
LZFG250/500 | 1/2Litre | 60/64 | 1000/200 | 250/500g | 250W | No | 25 |
LZFG-1000 | 4Litre | 80 | 900/1500 | 1000g | 250W | No | 27 |
LZJK1A | 0.13 | 200 | 600 | 0.05-0.8 | 1.1 | 0.55 | 190 |
LZJK2A | 0.23 | 250 | 500 | 0.12-0.28 | 1.5 | 0.55 | 390 |
LZJK3A | 0.35 | 300 | 480 | 0.15-0.5 | 2.2 | 0.55 | 426 |
LZJK4A | 0.62 | 350 | 400 | 0.3-0.9 | 3 | 1.1 | 752 |
LZJK5A | 1.1 | 500 | 330 | 0.6-1.6 | 5.5 | 1.1 | 1208 |
LZJK6A | 2.8 | 600 | 280 | 15-3.5 | 11 | 1.1 | 2108 |
LZSF4A | 0.37 | 300 | 410 | 0.2-0.4 | 1.5 | 0.55 | 466 |
LZSF5A | 1.2 | 450 | 312 | 0.6-1.2 | 5.5 | 1.1 | 1360 |
LZSF6A | 2.8 | 550 | 268 | 1.5-3.5 | 11 | 1.5 | 2126 |
LZSF7A | 4 | 650 | 220 | 2-4 | 15 | 1.5 | 2579 |
LZSF8A | 8 | 760 | 191 | 4-8 | 30 | 1.5 | 4116 |
