New siructure of impeller is backwards inclined double impellers equipped with honeycomb duct and dummy bottom. Therefore ,the slurry in the tand will cycle upward and downward in a fixed flow manner, which is helpful to the suspension of those coarse particles .Airand slurry are naturally sucked without need for foam pump.
Model | Volume | Impeller Diameter | Impeller speed | Capacity | Cell size | Power | Weight | |
Impeller | Scraper | |||||||
m3 | Mm | r/min | m3 /min | mm | Kw | kg | ||
XJK 1A | 0.13 | 200 | 600 | 0.05-0.08 | 500/500/550 | 0.75 | 0.5 | 190 |
XJK 2A | 0.23 | 250 | 500 | 0.12-0.28 | 600/600/650 | 1.5 | 0.5 | 390 |
XJK 3A | 0.35 | 300 | 483 | 0.18-0.4 | 700/700/700 | 2.2 | 1.1 | 426 |
XJK 4A | 0.62 | 350 | 400 | 0.3-0.9 | 820/900/850 | 3 | 1.1 | 752 |
XJK 5A | 1.1 | 500 | 330 | 0.6-1.6 | 1100/1100/1000 | 5.5 | 1.1 | 1208 |
XJK 6A | 2.8 | 600 | 280 | 1.5-3.5 | 1750/1600/1100 | 11 | 1.1 | 2108 |
SF 4A | 0.37 | 296 | 386 | 0.2-0.4 | 700/700/750 | 1.5 | 0.55 | 466 |
SF 5A | 1.2 | 450 | 312 | 0.6-1.2 | 1100/1100/1100 | 5.5 | 1.1 | 1360 |
SF 6A | 2.8 | 550 | 268 | 1.5-3.5 | 1700/1600/1150 | 11 | 1.5 | 2126 |
SF 7A | 4 | 650 | 220 | 2-4 | 1850/2050/1200 | 15 | 1.5 | 2579 |
SF 8A | 8 | 760 | 191 | 4-8 | 2200/2900/1400 | 30 | 1.5 | 4116 |
