Agitating tank
- 200 Set / Sets per Month
- Xiamen
- T/T
Product Details
Condition: | New | Application: | flotation, re-election, magnetic separation | Production Capacity: | 0.124 m3 |
Motor Type: | AC Motor | Power(W): | 1100 | Place of Origin: | Jiangxi, China |
Brand Name: | oasis | Model Number: | 500 | Certification: | ISO9001:2008 |
Warranty: | One year | After-sales Service Provided: | Overseas service center available |
Product Description
Agitating tank is suitable for flotation, re-election, magnetic separation, etc. right concentration of not more than 35% and solid components of the slurry particle size of less than 1 mm to stir, but also can be used for flotation agents and other non-metallic minerals, mixing, so that mine suspended particles and in full access to the Pharmacy, mixing, in order to create conditions for sorting operations.
This series of stirred tank are the following: Agitating tank ,Lifting agitating tank,High concentration agitation tank, High efficiency agitation tank,Specifications of shemical agitation tank
Model |
U nit | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Diameter tank | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Height | mm | 500 | 750 | 1000 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
Volume tank | m3
| 0.124 | 0.25 | 0.58 | 1.15 | 2.2 | 4.4 | 11.2 | 19.1 | 46 |
Impeller Diameter | mm | 150 | 240 | 240 | 310 | 400 | 550 | 630 | 700 | 1000 |
Impeller speed | r/min
| 1000 | 530 | 530 | 492 | 320 | 230 | 230 | 210 | 121.6 |
Power | kw | 1.1 | 1.5 | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 | 30 |
Weight | kg | 260 | 320 | 480 | 908 | 1280 | 1760 | 2700 | 18.5 | 8020 |
