Heavy Duty Laundry Clothes Ironing Machine/Ironing Board Industry/Shirt Automatic Ironing Machine
Features:
1. Pneumatic control, simple operation, low labor intensity.
2. Hands button operation, safe and reliable.
3. The NOMEX material at high temperature and high temperature of cotton cloth, durable, beautiful, air permeability, water absorption, good elasticity, ensure the ironing quality.
4. Plywood die molding, welding fixture that surface of the circulararc, straightness error is small, the ironing quality good. The basic forming a weld is little, not easy to deformation, stable movement.
5. Damping is good, ensure the smooth motion. Installed on the outer side of the frame, easy installation and maintenance.
6. Movement, clamping were completed by two cylinder, the movement is smooth, the clamping force is easy to control, ensure the ironing quality.
7. Pneumatic components manufacturing, stable quality, long service life.
Heavy Duty Laundry Clothes Ironing Machine/Ironing Board Industry/Shirt Automatic Ironing Machine
| Model | QZ2-23 |
| Steam Pressure(Mpa) | 0.4~0.5 |
| Steam Consumption(kg/h) | 15 |
Air Consumption(Mpa) | 0.55 |
| Wet Pump Pipe Size(inch) | Φ32 |
| Compressed Air Pipe Size( inch) | Φ3/8 |
Steam Inlet & Outlet Size( inch) | DN15 |
| Dimension (LxWxH mm) | 940×1010×1220 |
| Machine weight(kg) | 280 |
