Double-Layer Co-Extrusion Stretch Film Making Machine
USD $16,800 - $29,800
/ Unit
1 Unit(Min.Order)
- 20 Unit / Units per Month
- Dalian Port China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition: | New | Application: | Film | Plastic Processed: | PE |
| Place of Origin: | Shanghai, China | Brand Name: | MACH | Model Number: | FT-500x2 |
| Weight: | 3000kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Double-Layer Co-Extrusion Stretch Film Making Machine
1. General Introduction:
This machine is designed to produce stretch film(cling film) for industry or food packing, which is composed of eight parts – glue feeding part, 1st extruder part, 2nd extruder part, filter part, Die-head part, traction part, winding part and side film trimming part.
This machine uses LDPE and LLDPE as main materials to produce stretch wrapping film ( could produce one-side sticky film and the other side normal ), Adopting double screws and double two hoppers. This co-extrusion stretch film is widely used in packing area for architecture, auto parts, hardware parts,etc.
2. Characteristics:
1) Screw and cylinder are all made of 38 CrMoALA after nitrogen treatment, which has an advantage of corrosion resistance and endurance,etc.
2) The cooling device adopts cycle water cooling which provide the best transparent effect of the stretch film.
3) Rewinder adopts with friction-rewinding-type, with cutter device for edge correcting
3. Main Specification:
Model | FT-500x2 double-layer |
Diameter of Screw Stem | φ55mm*2 |
L/D Ration of Screw | 28:1 |
Material of Screw & Barrel | 38 CrMoALA |
Rational Speed of Screw Stem | 10-120rpm |
Width of T-die Head | 650 mm |
Heating Way | Casting-aluminum heating device |
Width of Traction Roller | 650 mm |
Width of Products | 200-500mm |
Thickness | 0.015-0.05mm |
Main motor power | 15kw*2 |
Heating Power | 30kw |
Max. output(kg/h) | 40 |
Machine weight | 3T |
Overall Dimensions (L*W*H) | 4500*2600*2550mm |
Applicable Material: LDPE (low density polyethylene) with
LLDPE(linear low density polyethylene),
which percentage can be 40% LDPE + 60% LLDPE
...
Contact Us
- Dalian Mach Co., Ltd.
- Contact nameCharles Yin
- Phone86-411-39647619, 83617286
- Address100 EAST LIAOHE ROAD, DD PORT, DALIAN, CHINA Dalian,Liaoning
