35L 55L 75L China Manufacturer Banbury Rubber Mixer Machine and Rubber Kneader Machine
US$ 18,000 - 26,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Rubber Kneader
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Reclaimed Rubber Production LineUS$ 30,000 - 50,000MOQ: 1 Set -
Laboratory 1.5L Pressurized KneaderUS$ 18,000 - 26,000MOQ: 1 Unit
-
Non-Pressurized Kneader for LaboratoryUS$ 18,000 - 26,000MOQ: 1 Unit
-
Pressurized Rubber Kneader MachineryUS$ 10,000 - 25,000MOQ: 1 Unit
-
3L & 5L Laboratory Pressurized Kneader in Good PriceUS$ 5,000 - 6,500MOQ: 1 Unit
Condition
New
Type
Rubber Kneader
Place of Origin
Liaoning, China
Brand Name
MACH
Model Number
X(S)N-55x32; X(S)N-75x32
Voltage
380V,
Power(W)
75kw-110kw
Dimension(L*W*H)
3300x1950x3020mm
Weight
8200-11600kgs
Certification
CE
Warranty
One Year
After-sales Service Provided
Engineers available to service machinery overseas
35L 55L 75L China manufacturer Banbury Rubber Mixer Machine and Rubber Kneader Machine
Specification of Rubber Kneader Machine:
Model |
X(S)N- 55x32 |
X(S)N- 75x32 |
X(S)N- 110x30 |
Total Volume |
125 Liter |
180 Liter |
250 Liter |
Working Volume |
55 Liter |
75 Liter |
110 Liter |
Driving motor power( KW ) |
75 KW |
110 KW |
185 KW |
Tilting motor power ( KW ) |
2.2 KW |
4 KW |
5.5 KW |
Tilting angle |
140 ° |
140 ° |
140 ° |
Revolution speed of rotor( front/rear ) |
32/26 rpm |
32/26 rpm |
30/24.5 rpm |
Pressure of compressed air |
0.6-0.8 MPa |
0.6-0.8 MPa |
0.6-0.8 MPa |
Consumption of compressed air |
≥ 1.0 m 3 /min |
≥ 1.2 m 3 /min |
≥ 1.5 m 3 /min |
Pressure of cooling water (rubber mixing ) |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
Pressure of heating steam ( plastics mixing ) |
0.5-0.8 |
0.5-0.8 |
0.5-0.8 |
Overall Dimension (mm) |
3370x1950x3020 |
3770x2570x3160 |
4060x2750x3590 |
Weight |
8,200 |
11,600 |
15,600 |
Electric-control system of Rubber Kneader Machine:
Picture see attachment.
1.Control power source
2.Automatic operating
3.Manual operating
4.Overload control
5.Alarm sounding of over temperature
6.Working current
7.Alarm sounding of discharging materials
8.Display of temperature
9.Number of times for mixing process: 1,2,3
10.Work preparation
11.Starting up of the main motor
12.Automatic-operating mode-Manual
13.Turning-Mixing chamber-Return
14.Rise·Float Weight·Fall
15.Automatic starting
16.On-Temperature Alarming-Off
17.On-Discharging sounding-Off
18.Main motor stop
19.Complete machine Stop
2.Automatic operating
3.Manual operating
4.Overload control
5.Alarm sounding of over temperature
6.Working current
7.Alarm sounding of discharging materials
8.Display of temperature
9.Number of times for mixing process: 1,2,3
10.Work preparation
11.Starting up of the main motor
12.Automatic-operating mode-Manual
13.Turning-Mixing chamber-Return
14.Rise·Float Weight·Fall
15.Automatic starting
16.On-Temperature Alarming-Off
17.On-Discharging sounding-Off
18.Main motor stop
19.Complete machine Stop
Exporting History:
We got CE certificate for our rubber kneader and export rubber kneader machine to Japan, Korea, Singapore, Indonesia, Malaysia, Ghana and other countries.
...
