XH7132 High Precision CNC Milling Machine Center
Technical Data
Specifications |
Unit |
XH7132 |
Table travel (X,Y,Z) |
mm |
620×350×500 |
Table size |
mm |
920×320 |
Number/Width/Distance of T-slot |
mm |
3-14-85 |
Distance from spindle nose to table surface |
mm |
100-600 |
Distance from spindle axis to vertical guideway |
mm |
395 |
Taper of spindle |
|
BT40 |
Spindle speed range |
rpm |
60-6000 |
Spindle motor power |
kW |
3.7 |
Rapid feed speed (X,Y,Z) |
mm/min |
18000 |
Feed speed (X,Y,Z) |
mm/min |
2.5-3000 |
Tool magazine capability |
qty |
16 |
Max. dimension of tool |
mm |
Φ120×200 |
Max. weight of tool |
kg |
8 |
Positioning accuracy |
mm |
±0.015 |
Repeat positioning accuracy |
mm |
±0.0075 |
Overall dimension |
mm |
2020×1870×2170 |
Machine weight |
kg |
3250 |
Standard configuration:
1. GSK 25I CNC SYSTEM
2. RS232 interface
3. Drum-type tool magazine capability 16 tools
Optional configuration:
1. FANUC OI mate-MD, SIEMENS 828D or HNC-22M, KND-2000M CNC system
2. Disc-type tool magazine capability 16 tools.
3. Automatic chip conveyor
4. NC A axis
feature:
1.We use Taiwan famouse brand high speed and high precision spindle.
2.We use Taiwan famouse brand umbrellla type tool magazine, Tool magazine capability: 16.
3.Cooling system use water pump in big Flow and high head ensure to be cooled fully under turning in high speed.
machine center photo:
About our company:
We are one of biggest manufacturer of producing CNC milling machine, Universal Milling Machine, CNC Lathe, etc in China. Our factory entered the top 8 machine tool builders in the world. Our universal milling machine sell to more than 100 countries and regions worldwide.
....
