5XZC-3 Corn seed cleaner cum thresher
Features
1. The machines sift based on aerodynamics and the surface speed difference of seed and impurities, adjusting the seed of the air current. As impurities are light, they are sucked into the ejection chamer,while seed is heavy and is transferred into a vibrating sift having passed through air sifting.
2. The vibrating is two layed with three exits which eject large impurities,small impurities and seed respectively,The vibration sift uses different sift for seeds of different sizes, if the seeds differ,the sifting differs too.
3. The machines are used for seed and agriculture byproducts processing,It is ideal for corn
4. The sift mesh used in the machine is made of high quality cool rolled galvanizing steel, with high precision and a long life span.The rubber ball sifting structure complies with international stardards,SanLIs patented rubber ball is highly elastic, endures,cold and is long lasting.
5. The machines use a vibrating motor as its vibrating source: the regulation of both scale and direction of vibration is convenient and accurate.Advanced technology.advanced specification,efficient,easy to operate and maitain, stable and cost effective.
The main performance indicators and technical parameters
Model | 5XZC-3 | 5XZC-5 |
Producitivity | 3000kg/h | 5000kg/h |
Exterior size(l*w*h) | 3970*1770*2720mm | 4970*1800*3050mm |
Power | 380v 50hz | 380v 50hz |
Weight | 1200kg | 1500kg |
Total power | 8.1kw | 10.5kw |
Selection rate | ≥97.5% | ≥97.5% |
Clarity | ≥ 97% | ≥ 97% |
Damaged rate | ≤ 0.5% | ≤ 0.5% |
Movementspeed | 10km/h | 10km/h |
Impurities rate | ≤ 2% | ≤ 2% |
Eviroment humidity | -20oC-50oC | -20oC-50oC |
Relative humidity | 20-80% | 20-80% |
