GR40-1600L Automatic Meat Vacuum Tumbler Machine

GR40-1600L Automatic Meat Vacuum Tumbler Machine thumbnail-1
GR40-1600L Automatic Meat Vacuum Tumbler Machine photo-1
US$ 5,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Warranty:
One Year
After-sales Service Provided:
Engineers available to service machinery overseas
Condition:
New
Contact Supplier Request Quote Chat Now
Shaoxing Kanglong Refrigeration And Fanner Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Condition New
Certification ISO
Name:GR40/100L Vacuum Tumbler




Keywords: GR40/100L Vacuum Tumbler



The machine structure is made of high quality stainless steel, compact structure, low noise, smooth operation, reliable performance, simple operation and high efficiency.

  Using Vacuum Tumbler obtain the following results:
1 Set working hours of tumbling
2 Set intermittent tumbling time
3 vacuum tumbling time
4 Continuous tumbling, intermittent tumbling, reverse discharge
5 are made of waterproof electrical control computer control
6 Reversible massage



Model
GR-40
GR-100
Volume
40L
100L
Production capacity
20kg/jar
50kg/jar
Power
0.95kw
1.3kw
Vacuum
0.04-0.08
0.04-0.08
Supply Voltage
220/380V
220/380V
Tumbling rotation
6TPM(Variable frequency stepless)
6TPM(Variable frequency stepless)
Host size
906×400×808mm
1060×600×980mm
Weight
75kg
95kg



Model

GR-400

GR-600

GR-1000

GR-1200

Volume

400L

600L(Vacuum suction type)

1000L(Vacuum suctiontype)

1200L(Vacuum suctiontype)

Production capacity

150-200kg/(jar)

225-300kg/(jar)

375-500kg(jar)

450-600kg/

Power

2.25kw

2.25kw

2.95kw

2.95kw

Vacuum

0.04-0.08

0.04-0.08

0.04-0.08

0.04-0.08

Supply Voltage

380V

380V

380V

380V

Tumbling rotation

6TPM(Variable frequencystepless speed)

6TPM(Variable frequencystepless speed)

6TPM(Variable frequencystepless speed)

6TPM(Variable frequencystepless speed)

Host size

1410×1020×1640mm

1500×1020×1640mm

2000×1020×1640mm

2100×1020×1720mm

Weight

480kg

520kg

680kg

760kg








Model
GR-400
GR-600
GR-2400
GR-1000
GR-1200
Capacity
400L
600L(Vacuum suctiontype)
2400L(Vacuum suction type)
1000L(Vacuum suction type)
1200L(Vacuum suction type)
Production capacity
150-200kg/tank
225-300kg/tank
900-1200kg/tank
375-500kg/tank
450-600kg/tank
Power
2.25kw
2.25kw
3.75kw
2.95kw
2.95kw
Vacuum
0.04-0.08
0.04-0.08
0.04-0.08
0.04-0.08
0.04-0.08
Supply Voltage
380V
380V
380V
380V
380V
Tumblingrotation
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
Host size
1410×1020×1640mm
1500×1020×1640mm
2350×1340×2210mm
2000×1020×1640mm
2100×1020×1720mm
Weight
480kg
520kg
1260kg
680kg
760kg

Model
GR-1600
GR-2000
GR-2400
GR-2800
GR-3200
Volume
1600L
2000L(vacuum suction type)
2400L(vacuum suction type)
2800L(vacuum suction type)
3200L(vacuum suction type)
Production capacity
600-800kg/Tank
750-1000kg/Tank
900-1200kg/Tank
1050-1400kg/Tank
1300-1600kg/Tank
Power
3.75kw
3.75kw
3.75kw
7kw
8.5kw
Vacuum
0.04-0.08
0.04-0.08
0.04-0.08
0.04-0.08
0.04-0.08
Supply Voltage
380V
380V
380V
380V
380V
Tumblingrotation
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
6TPM(variable frequency stepless)
Host size
2150×1230×2000mm
2200×1340×2010mm
2350×1340×2210mm
2500×1540×2200mm
2750×1540×2360mm
Weight
975kg
1090kg
1260kg
1450kg
1670kg





GR40-1600L Automatic Meat Vacuum Tumbler Machine
