AC rotary furnace
AC typical market analysis:
A:Chemical industry
Carrier carbon .Mainly used for catalyst carrier ,the function is:in addition to has accelerated chemical reaction rate of the carrier ,itself also has certain catalytic ability .Such as :load palladium carbon ,load silver carbon,load bromine carbon and so on,this kind of carbon used in vinylon carrier the dosage of activated carbon is largest ,basically use in PAV and PAVC production of catalyst carrier .A great number of enterprise in china use this kind of activated carbon are respectively :Anhui ,lanzhou ,jiangxi,guizhou,yunnan,guangxi,hebei ,shanxi and so on the several big vinylon production enterprise. The total amount of activated carbon about 3000 tons .Market price is about 23000 RMB/TON , production rate about 4:1( shell charcoal:AC).
B:Metallurgical industry
Mainly carbon plasma method and push immersion amalgamating technology of gold extraction by activated carbon .China has thousands of large and small gold mine,the largest amount use of activated carbon is fujian purple mountain gold mine,shanxi of taibai gold mine,hebei zhangjiakou gold mine,liaoning province wulong gold mine,liaoning row mountain building gold mine and so on.The most annual amount for above 300 tons ,minimum amount for a few tons.Every year china’s total dosage for 5000 tons.The price between 8000 and 13000,production rate about 2:1(shell charcoal:AC)The specific amount is unknown .
C:Water treatment industry
Mainly used for drinking water purification ,power plant raw water purification ,brewery of raw water purification ,sewage treatment etc.The demand in the previous year have more than tens thousands of tons that mainly Concentrated in the yangtze river delta ,the pearl river delta coastal cities .Such as :shanghai
yangshupu power plant ,shanghai open to environmental protection ,daqing chemical water plant ,guangzhou several big water plant ,etc. In Europe and the United States ,Japan,South Korea and the developed countries have more big dosage.every year this type of AC is the biggest quantity for AC application ,the price during 1000-1800USD per ton ,change rate is 1.8-2.2:1(charcoal:AC)
D:Other industry
Other carbon .Such as:Monosodium glutamate carbon ,medicinal carbon ,load Palladium carbon &MSG carbon.
| SERIAL | ITEMS | ROTARY KILN |
1 | Principle | Physical Steaming Aerobic Activation |
| 2 | Main material | 1.Manganess steel 2.Fire bricks&Insalate bricks 3.Waste gas steam boiler system 4.Gears &Roller 5.motors |
| 3 | Raw material | 1.hard wood charcoal(wood charcoal, coconut shell charcoal,palm shell charcoal,Kmili charcoal,etc) or charcoal mix with few raw shell mixed material, 2.natrual size or granular mesh size |
| 4 | Size: | (18-24)*(1.5-2.5)(dia)m ,one out put hole .not contain the boiler and feeding system |
| 5 | Procedure for AC | 1.After feeding ,material will convey slowly to the output part accroding to the Kiln turn around 2.blower will take the air into the Kiln at the feeding part to increase the temperature,at the same time steam injection into the Kiln for activation 3. Waste gas boiler get heating from the Kiln ,creat steam then react back to Kiln, 4.Output by circly in same step with the turnning of the Rotary Kiln 5.Draft fan and smoke pipe will take out the waste air and extra heating in the Kiln |
| 6 | Temperature control | 850-1100 degreee |
| 7 | AC quality | 1.can reach Iodine value 1500 2.hardness 80-95 3.can use as carrier AC FOR HIGH QUALITY AC |
| 8 | AC application | A: water purification B: Air clean C:MSG D:Alcohol E:Medicine F: Chromed plated G:Petrochemical industry H:Filter I:Carrier actived carbon |
| 9 | Capacity | 3-5tons per day based on:1000mg/g raw material :coconut charcoal or other hard shell charcoal Iodine value: 1000mg/g |
| 10 | Project time | 1 month preparation 2month installation,1month trainning,totally 4month |
| 11 | Start fire | first time 2days,normal 1day |
| 12 | Electricity consumption | 500-800KWH per day |
| 13 | Shipping | 4*20GP,4*40 OT ,1or 2 SPECIAL PLATFORM OR BULK SHIPPING |
