Specifications
shisha tablet punching machine1. 30 years experience
2. Best quality and thoughtful service
3. CE, ISO certificate
shisha charcoal tablet punching machine
Brief introduction of shisha charcoal tablet punching machine
1.shisha charcoal tablet punching machine
can press many different kinds of chips/tablets (circle, square, irregular, etc) by replacement of some spare parts.
2. The finished products’ surface is smooth and its pressure as well as density can be adjusted.
Pictures about the main parts of shisha charcoal tablet punching machine
1.the material of part is chromium steel, the feature is high hardness, wear-resistant, corrosion-resistant and not rust, the service time is 3-4 years( 6-8 hours working time per day),
2.the mold use wire cutting process technology, so the size of mold is very precise. if the mold is abrasion, we can provide the mold with low price and high quality, the mold is easy to repair and install.
Main features of the shisha charcoal tablet punching machine
1)Special design is suitable for light powder materials.
2)Reasonable structure with easy clearance and maintenance.
3)Transmission system in main gear box below airtight is completely separated, reducing noise and wear.
4)The model of hookah charcoal pressing machine is changeable.different model meet different requirements.
Two types of shisha charcoal tablet punching machine:
One Mechanical press type, the other is Hydraulica press type the first type: Mechanical press hookah charcoal pressing machine: (11-16 pieces per time, 20-40 times per minture)
The second type: Hydraulic press type shisha charcoal tablet punching machine( 36-48 pieces per time, 8-20 times per minture)
Include four parts:1) electric control cabinet, 2)touch screen, 3)hydraulic cyclinder,4) main engine.
The final products of shisha charcoal tablet punching machine:
1.The outlet shisha charcoal are good looking, smokeless, non toxic, long buning, one piece can burning more than one hour, easy fire and high heat.
2. we can provide the special binder formula after the order for free.
3. change the mould can be different shape, we can customize the mould as your requirements.
The whole production line related to shisha charcoal tablet punching machine
Raw materials----carbonization furnace----charcoal crusher----binder mixer----wheel mill----
shisha charcoal machine----finished shisha charcoal briquettes----dryer
If want to make good shisha hookah briquettes, must need to make attention on following:
1. Raw material: hardwood charcoal, coconut shell charcoal, bamboo charcoal are good material for make shisha briquettes.
2. only good quality hookah charcoal pressing machine can make good shisha hookah briquettes,our machine are patented products,
we have hydraulic type and mechanical press type for you choose.
3.It need to confirm the binder furmola is natural, smelless, nontoxic.we can provide the special binder foumula after order for free.
4.also we can depend on your specific situation design the production line to you.
Technical parameters of the shisha charcoal tablet punching machine
Model |
LTYJ-9 |
LTYJ-48 |
Applicable materials |
Charcoal powder, coal powder, sawdust, any powder material |
|
Capacity |
11-16 pieces/time 20-40 times/min |
48 pieces per time(30mm) 8-20 times/min |
Motor |
7.5 kw ( 4 pole) |
18.5 kw (4 pole_ |
Diameter of briquettes |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
20, 25,30, 35, 38, 40, 43mm( round): 20-40mm( cubic) |
Feeding materials |
≤3mm |
≤3mm |
Briquette shape |
Round shape and cubic shape or as customers’ request |
Round shape and cubic shape as customers’ request |
Pressure |
40-60tons (adjustable) |
40-150tons |
Pressure type |
Mechanical press |
Hydraulic press |
Overall size |
2500*950*1550mm (include conveyor) |
3500*2000*1800mm (include conveyor) |
Packing size |
1500*1200*1750mm |
2100*2100*1900mm |
Weight |
1500kg |
5500kg |
Pre-sale service:
1.According to the customer needs to recommend relative models machine.
2.According to the customer's special requirements to customize equipments.
3.Our engineers will supply the site and equipment drawing.
After-sale service:
1.According to the purchase contract,our company can send engineers to help installation.
2.The quality guarantee is 1 year,not including the wearing parts.
3.Collecting customer feedback,solve the real problems faced by customers.
4.Our company supply sapre parts the whole year.
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
Our working experience about the shisha charcoal tablet punching machine
Lantian Mechanical Plant, which located in Gongyi, Henan province,is a modern enterprisewhich setsthe scientific research,
production and sales as a whole.We have a modern management system,the first-class processing art, perfect detection means, high quality science and technology talent team
and after-service system. Our company has been rated as "Quality Trustworthy Unit" "Brand-name and Highquality products" and "QualityManagement Advanced Unit".In order to meet the different requirements of customers, we designed and researched many types of charcoal processing machine including charcoal & coal briquette machine, Shisha/hookah charcoal machine,sawdust charcoal briquette machine, tablet press machine, rotary dryer vertical dryer, belt mesh dryer
and mixer, crusher, blinder, etc.
Other assistant equipments of the shisha charcoal tablet punching machine
1)crusher
the first step of shisha charcoal tablet punching machine can crush the charcoal into powdery, the smaller the powder, the beeter tablets.
2) whell mixer
The second step is to mix charcoal powder with natural binder evenly. The reason why we use wheel mixer is that wheel mixer can not only improve shisha powder's density, but also press shisha powder into smaller size. (hookah charcoal pressing machine)
3) Box dryer:
The last step is to dry shisha briquettes in box dryer. Due to the liquid binder, shisha charcoal will have 15-20% water content, so we need to dry the briquettes to 3-5%( hookah charcoal pressing machine)
Welcome to our factory to check performance of the hookah charcoal pressing machine or contact with me at any moment.
