Outstanding features and factory direct press bamboo charcoal briquette making machine
The product description of charcoal tablet briquette machine
Machine press charcoal powder into small tablets, not only to press round shape, cubic shape, strip shape, ringlike shape, etc, but also can press with special words, company name, brand name, telephone number, etc.
The coconut shell, bamboo, hard wood is the best material of good quality and harmless shisha charcoal. Moreover, it also can be used for press coal powder, salt, fertilizer, sodium, carbonate, etc.
The production line of whole production line
Raw material----carbonizing----crushing----mixing----molding----drying
(1) Hydraulic type
The main engine, electric control cabinet(PLC), hydraulic cylinder and outlet conveyor belt comprised hydraulic machine.Hydraulic machine is our latest patented product with best molding effect.
According to different raw materials, the pressure, speed, punching times, shisha charcoal heights all can be adjusted and control. In addition, it has large pressure. Even if the sawdust is not easy molding,it also can be pressed into good shapes.Moreover, it has kinds of manual and automatic operation, more flexible and simple. The punching times are 711 times one minutes, so it can press about 20000 pieces one hour.If for 25*25*25 mm cubic shapes, it can press 48 pieces per time; if for 33mm round tablet, it can press 30 pieces per time. (2) Mechanical type
Ø Our mechanical plant produces mechanical tablet charcoal machine many years with matured experience.
Ø The punching times are 20-24 times one minutes, so it can press about 15000 pieces one machine. For 33 mm round shape, it can press 9 pieces per time; for 25*25 square shape, it can press 12 pieces per timeThe main parameters of charcoal tablet briquette machine
| Model |
Motor (KW) |
Capacity(t/h) |
Weight (t) |
Max Dia. (mm) |
Oversize (mm) |
|
| Coal | Charcoal | |||||
| LTJ-09 | 5.5 | 0.2-0.5 | 0.2-0.4 | 0.8 | 50 | 3.0*1.0*1.5 |
| LTJ-12 | 5.5 | 0.2-0.5 | 0.2-0.4 | 0.8 | 50 | 3.0*1.0*1.5 |
| LTY-S | 15+2.2+0.75 | 0.5-1.5 | 0.5-1.0 | 1.8 | 60 | 3.5*1.5*2.2 |
| LTY-M | 15+2.2+0.75 | 1.5-2.5 | 1.5-2.5 | 2.2 | 70 | 3.5*1.8*2.5 |
| LTY-L | 15+2.2+0.75 | 2.5-3.5 | 2.5-3.5 | 2.8 | 80 | 4.0*1.8*2.8 |
Ø Waterproof packing with the international export standard
Ø Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box.
Ø Other equipment will be packed by Color-Stripes Plastic Cloth.
