Specifications
zinc powder press machine,1.high efficiency
2.energy saving
3.environment protection
4.easy to transport and store
Full-automatic energy saving zinc powder briquette press machine
Brief introduction of Lantian zinc powder press machine:
The "Lantian" full-automatic zinc powder briquette press machine is mainly used for press various metallurgical pellet, metallurgical auxiliary materials, mineral powder, etc, powdery materials. This zinc powder press machine of big molding pressure, high yield efficiency, has been used in Baoshan Iron and Steel Plant, Baotou Iron and Steel Plant, Panzhihua steel, Anyang Iron and Steel Plant, etc, various of iron plant.
Requirements of molding material of zinc powder press machine:
1. The material particle is in 80-200;
2. Any metal is forbidden in the material for damaging the rollers' surface;
3. Feeding must be sufficient, to guarantee the ball moding rate;
4. Reminding is: when choosing the zinc powder briquette machine, shall pay attention to the rollers, better choose wear-resisting alloy forging.
The operation principles of the zinc powder press machine:
The structure of zinc powder press machine:
Our zinc powder briquette press machine is consists of three main parts: the feeding part; transmission part; molding part.
1. The feeding part: it is meanly for zinc powdery material from hopper evenly into the machine between the rollers for briquetting.
2. The transmission part: it is the main drive system, including the motor, reducer, triangle strip, coupling, driving spindle, open gear.
The technical parameters of zinc powder press machine:
| Model | Roller diam (mm) | Output (t/h) | Power (kw) | Regulator device | Ball size |
| 450 | 450 | 6-8 | 11-13 | Mechanical pressure regulating | User setting |
| 500 | 500 | 8-10 | 18-22 | Mechanical pressure regulating | User setting |
| 650 | 650 | 10-15 | 22-25 | Mechanical or hydraulic pressure regulating | User setting |
| 850 | 850 | 15-22 | 30-75 | Hydraulic pressure adjustment | User setting |
| 1000 | 1000 | 25-35 | 75-130 | Hydraulic pressure adjustment | User setting |
Brief Introduction of Our Factory:
Through 30 years of development and technology innovation, our Lantian Mechanical Plant has developped to a professional manufacturer that set design, production, and after-sale service as a whole. In order to meet the different requirementd of customers, we designed and researched many types of charcoal processing machines, include zinc powder briquette press machine, charcoal and coal briquette machine, shisha / hookah charcoal machine, sawdust charcoal briquette machine, charcoal extruder machine, etc, besides, we can also provide the assistant equipments for the whole production line, such as rotary dryers, vertical dryers, belt mesh dryer, feeder, crusher, mixer, conveyor, etc. In order to provide the best service to customers, we have also the certificates and patents of our machines.
Certificates:
Our service for our customers:
♥. Pre-sale service: design and manufacture machines for you as your special requirements, provide you with project, process design, and purchase programm.
♥. On-sale service: accompany with you to look around our factory, explain the manufacture process of our machines, and check the working performance of our machines.
♥. After-sale service: engineers are available to install and debugging equipments of the whole production line, besides, commissioning and training operators on site.
Packaging and shapping of our machines:
1. All the machines will be wrapped up with plastic film first (including the motor).
2. The plastic film bag wrapped machine, according to the size and weight to make wooden or iron box, put machine in and fixed the box after loading. (The box material can be made as your requirements)
3. The machine parts need to be put in a fixed container, should be fixed well, lest collision and wear, or lost.
