Specifications
Horizontal hydraulic sponge iron block making machine1.30 years experience
2.within 15 days delivery
3.12 months warranty
Horizontal hydraulic sponge iron block making machine
Brief introduction of hydraulic sponge iron block making machine:
"Lantian" brand automatic sponge iron block making machine can compress all kinds of metal scrap (iron scrap, copper scale, alunilium skimmings, titanium, etc), powder metal scrap (iron powder, aluminite powder, copper powder, etc), smelting additives, sponge iron, etc, into high density cylindrical cake ( weight 2-8 kg), the whole process no need to add any adhesive. The cake density can over 5T/M³ (different raw material with different cake density and weight), the compressed cake can be cast to furnace for using directly.
Structural features of sponge iron block making machine:
1. The machine frame part adopts integral cast steel, avoid the cracking of steel weldments, improve the stability and service life of the equipment.
2. Adopts advanced hydraulic drive technology and combination valve, using high quality wear-resistant oil seal, oil cylinder using the latest domestic high-tech craft processing and assembly, to ensure continious operation but do not weaken cylinder pressure.
3. Wear well, operate steadily; computer control, high degree of automation, low failure rate, easy to maintain, etc.
4. According to customers' using condition to equip with spiral automatic feeder and automatic chain discharg, lower the manual labor intensity.
Technical parameters:
| Model | Block size (mm) | Block density (T/M³) | Block weight (kg) | Shift output (T) | Power (kw) | Remark |
| LTM-200 | Φ90-100 | 4.0-5.2 | 2-3 | 3-6 | 11 | Manual fast speed |
| LTM-300 | Φ100-120 | 4.2-5.5 | 2-4 | 6-10 | 15-22 | Computer drive full automatic |
| LTM-400 | Φ110-140 | 4.2-5.5 |
3-5 | 10-16 | 22-30 | Computer drive full automatic |
| LTM-500 | Φ120-150 | 4.5-5.5 | 5-8 | 15-25 | 25-37 | Computer drive full automatic |
| LTM-600 | Φ130-160 | 5.5-6.0 | 6-9 | 17-27 | 30-42 | Computer drive full automatic |
| LTM-700 | Φ140-160 | 5.5-6.0 | 8-11 | 20-30 | 30-42 | Computer drive full automatic |
Working principle:
< We promise: >
1. Manufacturing high quality products:
From material purchasing to the finished products: we strictly according to the National Quality Inspection Standards, not only the shisha tablet machines, but also the ancillary equipments for the whole production line.
2. Be good faith producers:
Our quality is consistant, what we are doing just what we have been saying, what you need to do is to rest assured use our machines and equipments.
3. Warm and thoughtful service:
♥. Pre-sale service: design and manufacture machines for you as your requirements, provide you with project, process design, and purchase programm.
♥. On-sale service: accompany you to check the performance, and finish the shipment.
♥. After-sale service: engineers are available to install the equipments, commissioning and training operators on site.
Certificates:
Workshop:
The interactions between us and our customers:
Year after year, customers from different countries come to us to check the performance. After using our machines, they will retroaction the using conditions and give their precious opinions to us. The mutual trust and cooperation between us promoting our enterprise keep growing. Thank you very much for the encourage and help, we will never stop to improve the quality of our products and design new types to repay our old and new customers, give you a satisfactory answer.
