Specifications
Factory price hydraulic steel shavings baler machine1.30 years experience
2.within 15 days delivery
3.high efficiency
Factory price hydraulic steel shavings baler machine
Brief introduction of hydraulic steel shavings baler machine:
The "Lantian" series hydraulic steel shavings baler machine can extrude all kinds of metal leftover material (such as steel
shavings, steel scrap, aluminum scrap, copper, stainless steel scrap and automobiles waste scrap, etc.) into cuboid, octagon,
cylinder, etc, all kinds of qualified burden, can reduce the cost of transportation and smelting cost, also can improve the speed
of furnace. Molding as will as to ensure the original material of the same, for casting special material, the meaning of recycling
is larger, and furnace recycling out (iron) water rate is significantly increased. The recovery of loss less than 10%, such as the
raw iron after molding, can be used instead of cast iron, the casting cost savings for thousand yuan per ton. This series baling
machine is mainly suitable for steel mills, recovery processing industry and nonferrous, ferrous metal smelting industry.
The outstanding features of hydraulic steel shavings baler machine:
1. All machines are hydraulic-driven with alternatives of manual or automatic control.
2. Bale-discharging alternatives: turn out, push out, forward or manual discharging.
3. No fang bolts needed for installation; diesel engine can be used as power when electric power power is unavailable.
4. There are ten grades of baling force from 63-400 tons for customers choose, production efficiency from 4-30 tons.
5. The compression chamber size and the bag shape and size can be customized according to user's requirements.
The technical parameters of hydraulic steel shavings baler machine:
| Model | Fominal forece | Chamber size | Bale section | Power | Operation | Operation |
| LTH81-100A | 100KN/100T | 1000*700*500mm | 250*250mm | 11KW/15HP | Manual Valve | Turn bag |
| LTH81-100B | 100KN/100T | 1000*700*500mm | 250*250mm | 11KW/15HP | PLC Automatic | Turn bag |
| LTH81-125A | 125KN/125T | 1200*700*600mm | 250*250mm | 11KW/20HP | Manual Valve | Turn bag |
| LTH81-125B | 125KN/125T | 1200*700*600mm | 250*250mm | 11KW/20HP | PLC Automatic | Turn bag |
| LTH81-135A | 135KN/135T | 1400*600*600mm | 600*240mm | 20KW/30HP | Manual Valve | Push bag |
| LTH81-135B | 135KN/135T | 1400*600*600mm | 600*240mm | 20KW/30HP | PLC Automatic | Push bag |
| LTH81-160A | 160KN/160T | 1600*1000*800mm | 350*350mm | 20KW/30HP | Manual Valve | Turn bag |
| LTH81-160B | 160KN/160T | 1600*1000*800mm | 350*350mm | 20KW/30HP | PLC Automatic | Turn bag |
Working principle:
Put the baling materials in the machine box, hydraulic oil cylinder working to compression baling materials into all kinds of
metal bag piece.
Advantages of our hydraulic steel shavings baler machine:
This machine adopts hydraulic drive, compact structure, convenient moving, sinple operation, easy maintenance, reliable seal,
no foot screws during installation. The users can according to need customised packaging specifications, size, to maximize
match up the transport and storage. It is the ideal equipment for improving labor efficiency, reducing labor intensity, saving
manpower, reducing transportation cost.
Processing flow of hydraulic steel shavings baler machine:
Service for customers:
1. Pre-sale service
In service of users: production introduction, technical disclosure, provide solutions, quality assurance.
2. On-sale service
♥. In the process of using the equipments, our company regularly access to the customers, ask the feedback of users to
product quality and using conditions, etc, strive to further improve product quality, comprehensive performance.
♥. Arrange personnel to the users to train relevant personnel for using equipment, troubleshooting, debugging and
maintenance of specialized training.
3. After-sale service:
♥. Equipment (in normal use) within the warranty period, has warranty services. The whole machine warranty is 12 months,
expect the wearing parts.
♥. To the problem of customers' complaint about quality, immediately reaction, the marketing services personnel in 8 hours
to the scene, in the province within 24 hours, 48 hours for domestic and foreign countries within 72 hours.
Certificates:
Work place:
The interactions between us and our customers:
Year after year, customers from different countries come to us to check the performance. After using our machines, they
will retroaction the using conditions and give their precious opinions to us. The mutual trust and cooperation between us
promoting our enterprise keep growing. Thank you very much for the encourage and help, we will never stop to improve
the quality of our products and design new types to repay our old and new customers, give you a satisfactory answer.
Welcome sincerely to our company to build business internations!
