hot air wood chip rotary dryer
Introdutcion of the hot air wood chip rotary dryer
The hot air wood chip rotary dryer is a common and wide using drying device in mining industry. It is suitable for drying metal powder, mining powder, clay, coal and others. It is formed of body roller, lifting blades, driving device, supporting device and sealing ring. And it has the features of high efficiency, high drying strength and easy operation, which is an ideal equipment for drying high humidity materials.
Cost of various energy sources | Heat consumption | Energy efficiency | Actual heat energy | Amount of energy consumed |
Electric dryer | 8600 K cal | 95% | 817 K cal/kw.h | 150 kw.h |
Coal dryer | 25% | 1750K cal/kg | 49 kg | |
Fuel dryer | 80% | 8240K cal/kg | 0.4 kg | |
Heat pump dryer | 30% | 2580 K cal/kw.h | 33 kw.h |
Application of the hot air wood chip rotary dryer
1.The hot air wood chip rotary dryer made in our factory is mainly used for chemical, mining, metallurgy industry, like mineral, slag, coal, metal powder, clay, kieselguhr, kaolin, sand, lignite, slica sand...
2. The hot air wood chip rotary dryer can used for agriculture and fertilizer industry, like sawdust, straw, stalk, leaves, starch pulp, dregs of decoction, pomace, bagasse, slurry, organic fertilizer, inorganic fertilizer and others.
3. It also can used for drying the special materials, such as all kinds of crystalline, argil, magnetic powder, inorganic mud, lime slurry, aluminum mud, mineral mud and others.
The Features of the hot air wood chip rotary dryer
1. High drying strength, high dealing capacity, low consumption and low drying cost.
2. Our rotary dryer for hot sale has the characteristics of high temperature resistance, and it can use high temperature hot air to dry the materials fastly.
3. It adopts self-aligning riding wheel structure, the riding wheel and roller ring cooperate well, and it can greatly reduce the wearing and power consumption.
4. Special designed catch wheel structure, which reduce the horizontal thrust caused by the equipment tilt work.
5. High resistance of overload ability, roller body is stable working and higher reliability.
Installation of the hot air wood chip rotary dryer
1. The hot air wood chip rotary dryer should be loaded and installed on the level ground, better on the concrete floor, use foot screws fixed.
2. The roller body should be verticle on level ground.
3. After installation, we should check whether there is loose bolt and parts, then tighten it.
4. The hot air wood chip rotary dryer should be equiped with power cord and control switch.
5. Complete check, we should start the dryer without any materials in for about 3 minutes, if the dryer work well, we can put the materials for production.
Maintain of the hot air wood chip rotary dryer
1. We should add oil regularly. The lifetime of bearing is based on the good lubrication, which effect the lifetime and running rate of the rotary drum dryer. So we should cleaning oil and close them well. Some parts we should add oil is transmission bearing, rolling bearing, gears, moving bearing and slide plate.
2. The new installed tyre are easily loose, we should check them often.
3. Pay attention on whether every part of machine works normally.
4. Check the wearing degree of easy wear parts, and change the worn and damaged parts.
5. Remove the dirt of chassis plate where load the live device, in case of the live bearing can't move when there is materials not be broken appeared.
6. The temperature of bearing oil goes up, we should stop the machine and check.
7. If there is rushing sound when the rotating gear is running, we should stop the machine and check.
Pre-sales service: We can assist you analyze your particular requirements and offer you a single machine,
a multi-stage production, or a complete production line.
After-sales service: We can offer you related technical support and guide you to install the products,or send
our engineer to your factory for the installation. Also we provide one year warranty for all of our products.
Payment and Delivery terms
(1).Payment:TT,LC,Western union or other payments
(2).Packing: Naked or can be customized
(3).Allocate and allot according to supplier’s regulation at random.
(4).Liability for breach of contract: Resolve through consultation.
(5).Other unaccomplished matters, are resolved through consultation separately by both sides
Skill standard, Quality guarantee
(1).The technical standard consults the standard of supplier’s enterprise.
(2).Equipment must be100% brand new when leaving factory.Malfunctions which are caused by
manufacturer’s default and quality will be responsible by manufacturer.Other malfunctions which
are caused by operation mistake,man-made problem,etc will be responsible by client herself.
