Lantian Factory Rice husk powder grinding machine
- 66 Set / Sets per Month
- Shanghai Qingdao etc
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Lantian |
Model Number: | UP-2 | Voltage: | 380V | Power(W): | 7.5kw |
Weight: | 800kg, 800-2000kg | Dimension(L*W*H): | depend on the types | Certification: | CE ISO |
Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Lantian machine rice husk powder grinding machine
Brief introduction:
1.Application field:Wood processing plant, raw material processing plant, wood powder raw material processing plant, wood broad processing factory.
2.Common use:Charcoal machine auxiliary equipment;Biomass pellet machine auxiliary equipment;wood powder machine auxiliary equipment;Feed crusher machine auxiliary equipment ,etc.
3.Suitable raw materials:kinds of scrap wood /tree branch/bamboo/Straw,/dressing
Working principle of rice straw grinding machine:
Efficient crusher inpact blade cutting and high speed air flow,collision double crush functions in an
organic whole,and can complete the material separation process at the same time.Produced in the
process of blade cutting grinding,rotor high-speed airflow,along with the blade cutting direction,
materails in the airflow speed,and repeated shocks make material by double crush at the same time
accelerated material crushing rate.
Suitable Material of rice straw grinding machine:
-Tree branch
-Wood chips
-Peanut shell,biomass shell etc.
-Sugarcane waste.
-Coconut shell,palm shell.
Technical parameters of wood material crushing machine:
Model | 400 | 500 | 600 | 700 | 800 | 1000 |
Cutter diameter( mm) | 400 | 500 | 600 | 700 | 800 | 1000 |
Cutter quantity (piece) | 4 | 4 | 4 | 4-6 | 4 | 6-8 |
Cutter length( mm) | 90 | 100 | 150 | 200 | 230 | 260 |
Feed inlet diameter( mm) | 160×200 | 180×200 | 200×200 | 200×250 | 250×300 | 300×400 |
Main arbor rotation rate (r/min) | 2600 | 2600 | 2600 | 2300 | 2000 | 2000 |
Power( kw) | 7.5-11 | 15 | 18.5-22 | 22-30 | 37-45 | 75+7.5 |
Capacity (kg/h) | 600-900 | 800-1000 | 1200-1500 | 1800-2000 | 2500 | 3000-4000 |
Discharge size (mm) | According to customer demand, adjust fineness during replacing the different screen.
|
