High quality Lantian plant shisha charcoal briquette dryer oven for hookah
Introduction of charcoal briquettes drying oven1.This shisha charcoal briquette dryer for hookah is mainly drying charcoal ball ,coal ball ,iron ball and others ,after briquette ,the ball have moisture ,can't use directly .after drying can use directly as fuel or smelting.
2.we have produce mesh belt dryer more than 30 years.and exported a lot of machine to the world.hope you visit our factory and see the working site.
3.Shiasha charcoal dryer machine is mainly directly convey pressed finished ball on flat conveyor through conveyor, and uniformly distributes finished ball on dryer through scraper blade at upper end of flat conveyor, thus improving air permeability of ball, further reaching drying effect.
Features of dryer
1) By using the forced ventilationfuntion, there are adjustable air distribution inside the oven. The materials can be dried uniformly. |
2) Heating source: electricity, steam, far infrared of steam and electricity. |
3) Temperature allowed with this fruit vegetable dryer heat 50°C-140°C,the maximum is 150°C. Electricity heat 50-350°C. |
4) automatic control system and computer control system for your choice. |
5) If you have special request, we also could customize the pork drying machine for you. |
6) Baking plate dimension: 460*640*45mm |
Application of charcoal briquettes drying ovenThe shisha charcoal briquette dryer for hookah is a common continuous dryer equipment, it is widely applied in chemical, foodstuff, pharmacy, construction material, and electronic industry, and particularly it is adapt to dry the raw materials which have good air permeability and shaped in sheet, strip or granule. For ointment stuff, the wisest way to dry it are: shaped those stuff first, then drying it.
Working principle of charcoal briquettes drying oven
1.The raw material was transported into the feeder and put on the mesh-belt uniformly. Then the transmission device will carry the mesh-belt to keep moving forward.
2.In the mesh- belt, there are some heater strips. When the fruit mesh belt dryer the power, the heater strips will produce great heat to dry the raw material.
3.The multil- ayers coal briquettes mesh belt is composed of several unit. Each unit is interlinked, so that the hot air can be successively used. And it can improve the drying effect.
4.The hot air alway around the surface of the raw material and turn water into water vapor, then the raw material complete the drying process.
5.At the top of the coke briquette belt dryer machine , there some small blowers. The small blowers will take the water vapor out and left the dried raw material.
Technical parameter of charcoal briquettes drying oven
Model | KHWD6 | KHWD8 | KHWD10 | KHWD12 | KHJWD16 | KHWD20 | KHWD24 | KHWD30 |
Width of mesh belt(mm) | 600 | 800 | 1000 | 1200 | 1600 | 2000 | 2400 | 3000 |
Length of drying section(m) | 6-12 | 6-12 | 6-16 | 8-16 | 8-22 | 10-26 | 12-30 | 12-40 |
Length of feeding section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 |
Length of transmitting section(m) | 1 | 1 | 1 | 1 | 1 | 1.5 | 1.5 | 2 |
Drying area(m2) | 3.6-36 | 4.8-48 | 6-80 | 7.2-96 | 12.8-105.6 | 20-260 | 28.8-360 | 36-600 |
Layers NO. | 1-5 | |||||||
Interlamellar spacing (mm) | 400-600 | |||||||
Carrying capacity | 90-200 Kg/m2 | |||||||
Operation temperature (°C) | carbon steel≤400 C°,stainless steel≤600 C° | |||||||
