Machinery Quite Environmental Wood Carbonizing Furnace

Name: Machinery Quite Environmental Wood Carbonizing Furnace
Brand: Lantian
SKU: 141418142
Availability: InStock

Gongyi Lantian Mechanical Plant

US$ 1,500 - 6,600 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

Lantian

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai etc

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name Lantian

Model Number HQ-LK

Voltage 220V 380V 450V 600V, 380v

Power(W) 7.5kw

Weight 1500kg

Dimension(L*W*H) depend on the types

Certification CE ISO

Warranty One Year, 12months

After-sales Service Provided Engineers available to service machinery overseas

Machinery Quite environmental wood carbonizing furnace

Product Description

Brief description	1.Charcoal carbonization furnace for biomass,is a kind of new air flow type carbonization furnace.It is used to make charcoal from wood and all kinds of biomass.It adopts new advanced hot air carbonizing technology,greatly improves the carbonization rate 99%,compared with the carbonization rate 80% of tradtional carbonization stove!This kind stove is safe and easy to operate,thus it is very famous among many industries like charcoal making industry and bolier industry! 2.Carbonization furnace have four tanks inside.Every tank weight 250kg.
Usage	It used to BBQ and fire
Working principle	A: Prepare the raw material and pack them in the inner stove; B: Use the hoist to hang the inner stove to the outer stove, and then cover the cap; and then connect the cap and inner stove and seal them; C: then fire the outer stove, and use the purification tank to collect the smoke; D: when it produce the fuel gas, you can use the fuel gas to carbonzie the raw material which save a lot of fire material. E: when finish the carbonization, use the hoist to hang the inner stove out to the ground, and then use the hoist to hang another inner stove to carbonize again.
Features	1.Easy to operate and maintain, higher safety, energy saving 2.High carbonization rate ,no smoking, little pollution, high efficient.

Technical Parameters

MODEL	POWER	CAPACITY	WEIGHT	Loading capacity	Temp	EQUIPMENT LIST
THL-1	0.75KW	3t/24hrs	4T	2.75*3 (cbm)	400-600 ℃	1outer furnace, 3Inner pots,3covers, 1purification tank, 1*3t lifting device
THL-2	0.75KW	6t/24hrs	8T	2.75*6 (cbm)	400-600 ℃	2outer furnaces, 6Inner pots,6covers, 2purification tank, 1*5t hoist equipment with motor
THL-3	0.75+1.5KW	9t/24hrs	12T	2.75*9 (cbm)	400-600 ℃	3outer furnaces, 9Inner pots,9covers, 3purification tank, 1*5t hoist equipment with motor
THL-4	0.75+1.5KW	12t/24hrs	16T	2.75*12 (cbm)	400-600 ℃	4outer furnaces, 12Inner pots,12covers, 4purification tank, 1*5t hoist equipment with motor
PS 1: Load 2.5tons machine-made briquettes, 8hours will get 1000kg machine-made charcoal. PS 2: Load 2tons natural wood, 8-10hours will get 600kg-800kg natural charcoal. PS 3: Normally it takes 8-10hours. Maybe longger for fresh wood to remove moisture. PS 4: Heat value: 5500-7000KCAL / KG. PS 5: Raw material: Machine-made charcoal, wood ,coconut shell, wood briquette, bamboo, almond shell, plam shell. PS 6: Operation: one people one shift ( one day two shift). PS 7: Energy consumption 20-30kg firewood or 15kg liquid gas.
