double shaft crushing scrap foam shredding machine
Whatsapp : +86 15937198193
| ITEM | DESCRIPTION |
| working principle | firstly gear motors are mounted directly on the mill drive shaft , driven shaft transmitted through the gear shift, so that the stationary cutter knife and the shell is formed on the drive shaft relative motion. Active shaft helical cutter staggered, so , once the material entered, while being cutting , torn and pulled by blade and moreover combined with low speed biaxial rotating , the materials are broken. |
| machine structure | motor , reduction gear, electric control cabinet(PLC) ,blade of double shaft , sieve and machine frame |
| blade material | special alloy steel which refined by forging and milling process(wear-resistant and durable) , like 55sicr , 9crsi , cr12mov ,DC53,D2 , SKD11 and etc; for cutting different things , and should use different material blade .
|
what raw material can be crushed by your machine? | 1.PPC scrap, waste paper, corrugated paper, cardboard and carton etc. 2.Various hollow container:plastic beverage cans,plastic drums,steel drums,packing box ,pail pack,plastic bottles, plastic bucket products. 3.Waste household appliances:TV,washing machine,refrigerator shell. 4.Pipe:large pipe,pipe fittings,PEpipe. 5.Waste template:wooden pallets,plastic pallets,forklift pallet, sawdustboard. 6.Waste tire and rubber products. 7.Scrap metal:car shell.aluminum alloy,waste alumimum casting,engine casing,plumbum and steel plate of thickness below 5mm. 8.The kitchen garbage,household garbage,animal carcasses,RDF derivatives,medical waste ,straw,garden waste. |
| features | low speed , high torque , machine will reverse running automatically if overload |
| function | through cutting and extrusion to reduce the material size for saving transportation cost and space(coarse smash) , or improve the handling capacity on further fine grinding , anyway , it is used in wastes recycling field |
| working life of spare parts | it is not fixed , mainly depends on the hardness of your raw material , usually comes as 6-12 months |
| crushing effectiveness |
tire wood timber carton box and scrap cloth |
specifications for all model multi-function scrap foam shredding machine
| Model | Feeding Hole (mm) | Max feeding size(mm) | Discharging Hole(mm) | Handling Capacity | Power(KW) | Wt(ton) | Dimension(L*W*H) |
| HDSS-400 | 450*600 | 400 | 10-30 | 0.2-0.4 | 4*2 | 0.8 | 2000*670*1600 |
| HDSS-600 | 500*600 | 85 | 10-40 | 0.5-0.7 | 18.5 | 2.2 | 1720*660*1850 |
| HDSS-800 | 700*800 | 100 | 10-50 | 1-1.2 | 30*2 | 3.6 | 1910*850*1990 |
| HDSS-1000 | 900*1000 | 120 | 14-70 | 2.5-3 | 75 | 6.5 | 2000*1070*1990 |
| HDSS-1200 | 1000*1200 | 150 | 20-60 | 3-3.5 | 90 | 10 | 2400*1090*2270 |
| HDSS-1600 | 1400*1600 | 160 | 20-100 | 3.5-4.5 | 132 | 19 | 2400*2200*3500 |
| HDSS-1800 | 1800*2000 | 180 | 30-100 | 7-8 | 180 | 30 | 2500*2400*5200 |
Detailed Photos from our workshop on Scrap Foam Shredding Machine
- Before sending the machine , we will test , for any problems , we will find timely and moreover make approprite adjustment , speak from this aspect , we can guarantee each machine comes in 100% good quality , and you can use directly after connect with electric power
- Operating video will be sent to clients together with instruction book , to help them for a better use.
- Any Problems occurred while running , professional advice(technic support) will be given by us within 24 hours via email .
- Ware parts of hammer , blade and screen mesh are supplied from us all the year round .
- One year guarantee for whole machine except spare parts .
We are a trading company , but now only cooperate with several fixed machinery factory which produce good quality equipment . In past three years , with more and more understanding on product knowledge in the whole(true) communication process , and naturaly we will give up the low credibility and poor quality supplier , so.....choose us as a partner , firstly means that you are guaranteed on machine performance . As for that price , maybe we are not the lowest , but I am sure we are the best as dealed . To give you a reference , here as below I show you the main production line we are versed in :
1. tradtional squeezing edible oil + refining
2. steel wire nail
3. sawdust briquetting
5. fruit /tuber vegetable cleaning( peeling) + cutting+ dehydration oven + vacuum package (Nitrogen Filling)
6. tofu machine
7. coffeen bean roaster + grinder (also applicable for various seasoning , sugar , salt and etc )
8. waste vehicle oil purifier processing recycling equipment for getting oil and metal pieces
9. motor rotor crushing separating machine
1. Q:, how should I contact you ?
A: Pls find my below photo :
2. Q: What information we should provide for getting a quotation on suitable model ?
A: 1. show me the photo of your raw material ? And moreover advise its biggest size ?
2. what final size you required after shredding ?
3. what handling capacity you asked per hour ?
3. Q: How we can get to your factory for a visiting ?
A: XINZHENG INTERNATIONAL AIRPORT is the nearest one from us , you can fly there and then we pick up you .
If you take the bullet train , our nearest station is GONGYI NAN.
