waste tyre recycling plant
Working Principle of Waste Tyre Recycling Plant :
gear motors are mounted directly on the mill drive shaft , driven shaft transmitted through the gear shift, so that the stationary cutter knife and the shell is formed on the drive shaft relative motion. Active shaft helical cutter staggered, so , once the material entered, while being cutting , torn and pulled by blade and moreover combined with low speed biaxial rotating , the materials are broken.
Suitable Material :
Shredder Machine is designed for coarse smash which happened before recycling solid waste , will be widely used for plastic , tire , carton box , textile , wood timber and other kind of leftover material , and main purpose is to increase bulk density for saving transportation cost and space .
Feathers of Waste Tyre Recycling plant :
1. low rotation rate , low noise and large moment of torsion
2. electrical control cabinet (with function buttons for "on , off , reverse and overload automatic reverse ")
3. 55sicr material cutter with long working life (other options for 9crsi, and cr12mov , and mainly depends on user' request .
specifications for all model Waste Tyre Recycling Plant :
| Model | Feeding Hole (mm) | Max feeding size(mm) | Discharging Hole(mm) | Handling Capacity | Power(KW) | Wt(ton) | Dimension(L*W*H) |
| HDSS-600 | 500*600 | 85 | 10-40 | 0.5-0.7 | 18.5 | 2.2 | 1720*660*1850 |
| HDSS-800 | 700*800 | 100 | 10-50 | 1-1.2 | 30*2 | 3.6 | 1910*850*1990 |
| HDSS-1000 | 900*1000 | 120 | 14-70 | 2.5-3 | 75 | 6.5 | 2000*1070*1990 |
| HDSS-1200 | 1000*1200 | 150 | 20-60 | 3-3.5 | 90 | 10 | 2400*1090*2270 |
| HDSS-1600 | 1400*1600 | 160 | 20-100 | 3.5-4.5 | 132 | 19 | 2400*2200*3500 |
| HDSS-1800 | 1800*2000 | 180 | 30-100 | 7-8 | 180 | 30 | 2500*2400*5200 |
Detailed Photos of Waste Tyre Recycling Plant :
Photo of Cutting Blade (spare parts ):
crushing effectivenes:
wood timber
scrap cloth and carton box
Photos of Gear Case
- Before sending the machine , we will test , for any problems , we will find timely and moreover make approprite adjustment , speak from this aspect , we can guarantee each machine comes in 100% good quality , and you can use directly after connect with electric power
- Operating video will be sent to clients together with instruction book , to help them for a better use.
- Any Problems occurred while running , professional advice(technic support) will be given by us within 24 hours via email .
- Ware parts of hammer , blade and screen mesh are supplied from us all the year round .
- One year guarantee for whole machine except spare parts .
We are a trading company , but now only cooperate with several fixed machinery factory which produce good quality equipment . In past three years , with more and more understanding on product knowledge in the whole(true) communication process , and naturaly we will give up the low credibility and poor quality supplier , so.....choose us as a partner , firstly means that you are guaranteed on machine performance . As for that price , maybe we are not the lowest , but I am sure we are the best as dealed . To give you a reference , here as below I show you the main production line we are versed in :
1. tradtional squeezing edible oil + refining
2. steel wire nail
3. sawdust briquetting
5. fruit /tuber vegetable cleaning( peeling) + cutting+ dehydration oven + vacuum package (Nitrogen Filling)
6. tofu machine
7. coffeen bean roaster + grinder (also applicable for various seasoning , sugar , salt and etc )
8. waste vehicle oil purifier processing recycling equipment for getting oil and metal pieces
9. motor rotor crushing separating machine
