Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines

China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines

China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines thumbnail-1
China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines thumbnail-2
China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines thumbnail-3
China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines photo-1
China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines photo-2
China Generator Factory 20kw to 1000kw Diesel Generator With Cummins Engines photo-3
US$ 4,999 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
Puyang
Model Number:
PFC25-1250
Contact Supplier Request Quote Chat Now
Dalian Puyang International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name Puyang
Model Number PFC25-1250
Output Type AC Three Phase
Speed 1500/1800RPM
Frequency 50/60HZ
Rated Power 20-1000kw
Rated Voltage 230/440v
Rated Current 36-880A

China generator factory 20kw to 1000kw diesel generator with cummins engines





    China generator factory 20kw to 1000kw diesel generator with cummins engines



Genset:

Rated output: 20kw-1000kw

Rated voltage: 400/230

Rated current:36-1800A

Rated frequency: 50/60Hz

Power factor: 0.8lagging

Phases arrangement:3P4W

Rated speed:1500/1800rpm

Fuel consumption:196-210g/k.wh

Noise level: 105db open type, 75db silent type,@7m

Engine:

Brand ; CUMMINS

Type: water cooled,four stroke,direct injection,natural or turbocharged

Cooling method: closed water-cooled

Starting method: electrical start

Speed governor: electronic governor

Alternator:

Brand: Stamford,Marathon,Lemory Somer

Rated output: 20kw-1000kw

Excitation method: brushless

Voltage regulation: AVR

Protection class: IP22

insulation class:H





Genset

Rated power

CUMMINS DIESEL ENGINE

Dimension&Weight

model

(kw/kva)


Model

Fuel consumption(L/H)



Weight(Kg)


Dimension(mm)

PFC25

20/25

4B3.9-G1

5.1

1650×730×1180

560

PFC56

45/56

4BTA3.9-G2

10.3

1850×730×1220

680

PFC93

75/93

6BT5.9-G2

19.2

2250×790×1250

1020

PFC125

100/125

6BTAA5.9-G2

25.6

2350×840×1280

1160

PFC175

140/175

6CTA8.3-G2

37.1

2410×900×1360

1220

PFC200

160/200

6CTAA8.3-G2

41

2500×950×1430

1280

PFC250

200/2500

MTA11-G2A

46.8

2800×970×1630

2210

PFC313

250/313

NTA855-G1B

68

3010×1000×1750

2950

PFC375

300/375

NTAA855-G7

86

3160×1140×1860

3150

PFC450

360/450

KTA19-G3

97

3270×1360×1990

3850

PFC500

400/5000

KTA19-G3A

108.3

3290×1360×1990

4000

PFC625E

420/525

KTAA19-G5

113

3400×1550×2060

4250

PFC650

520/650

QSKTAA19-G3NR2

143

3420×1550×2060

4330

PFC750

600/750

KTA38-G2

167

3900×1810×2500

7800

PFC800

640/800

KTA38-G2B

172

3980×1810×2500

8200

PFC910

728/910

KTA38-G2A

191

4020×1810×2500

8360

PFC1000

800/1000

KTA38-G5

209

4150×1810×2460

8700

PFC1250

1000/1250

QSK38-G5

262

4750×2080×2410

10800









Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Dalian Puyang International Trade Co., Ltd.
Business Type
Manufacturer, Trading Company
Year Established
2005
Factory Size
50,000-100,000 square meters
Total Employees
51 - 100 People
Contact Supplier Request Quote Chat Now
