Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 4-stroke Air Cooled 5kva Silent Genset

4-stroke Air Cooled 5kva Silent Genset

Name: 4-stroke Air Cooled 5kva Silent Genset
Brand: PUYANG
SKU: 141415982
Availability: InStock

Dalian Puyang International Trade Co., Ltd.

4-stroke Air Cooled 5kva Silent Genset thumbnail-1

4-stroke Air Cooled 5kva Silent Genset photo-1

US$ 300 - 999 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Liaoning, China

Brand Name:

PUYANG

Model Number:

PFD3600

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Liaoning, China

Brand Name PUYANG

Model Number PFD3600

Output Type AC Single Phase

Speed 3000/3600RPM

Frequency 50/60Hz

Rated Power 5KVA

Rated Voltage AC 220V

Rated Current N/A

Specifications

5kva silent genset
1.Low oil alert system
2.four wheel kits
3.Maintenance-free battery
4.Convenient use

4-stroke air cooled 5kva silent genset

Model	PFD3600
Frequency(Hz)	50/60
Rated AC output(KW)	2.8/3.0
Max. AC output(Kva)	3.0/3.3
AC voltage	220,230,240/110,120,110/220,120/240
DC Output (V/A)	12/8.3
Engine model	JD178
Engine type	air-cooled,0#Diesel as the fuel
Fuel tank capacity (L)	12.5
Continuous work (h)	9
Starting system	Electric starter with battery
Lubrication Oil Volume [Liter]	1.1
Noise Level at 7m(dB)	70
Gross Weight(kg)	140
Dimension(mm)	960490570
20ft Container QTY	72
40ft Container QTY	144

Strong Power

All generator sets are equipped with four-stroke engines.

Low Noise Running

High effective combustion system ensures complete combustion, Besides, a large silencer dampens exhaust noise and engine sounds which are contained by a double-wall structure and absorbed by a liner.

Digital Control Panel

All the control units of the generator sets are on one panel, a monitor of the panel will display the real-time working data of the generator set such as its output voltage and current etc. Besides, the running trouble of the generator will also be displayed on the panel.

Low Oil Alarm System

Before the oil level drops to the limited level, the generator set will stop automatically. The whole set can be

restarted only if the oil is refilled.

Application of New AVR

The AVR (Automatic Voltage Regulator) not only can smooth the output but also can provide reasonable protec-tion against the overload of the whole set, thus avoid damage to the set.

Advanced Alternator Winding

Waveform distortion is kept at a minimum level and the output is stable. The winding design protects the generator from short circuits and provides a stable output while running inductive loads.

ATS (Automatic Transfer Switch)

On the inheriting of the original

general-purpose generator set, diesel generator sets with digital control panel can be equipped with a made ATS(automatic transfer switch). ATS, in its preset intervals, can automatically check and monitor the running of the genset to ensure the genset in good working condition. Meanwhile, ATS will monitor the utility power, if utility power fails or the voltage and frequency of the utility power become abnormal, ATS will give commands to start the genset automatically.
