Specifications
Single Phase Genset1.Gasoline Fuel
2.Single Phase Output Type
3.Air Cooling Method
5.Low Gas Consumption
Mini Natural Gas Single Phase Genset China Wholesale
General Parameters of the Single Phase Genset
1.Powered by 4 stroke and air cooling method
2.Circuit breaker protects overload operation
3.Large fuel tank ensures 10.5 hours of continuous running time
4.AVR alternator provides steady voltage and current
5.Emergency low oil alert warn the low lube oil level
6.Double large efficient muffler and patented soundproof canopy lower noise to 69dB
7.Mini vibration and smooth running features
8.Recoil starting,single phase and 100% copper wire
| Frequency | 50/60Hz |
| Rated AC output | 2.5kW |
| Max. AC output | 3.0kW |
| AC voltage | 110,120,220,230 |
| DC Output | 12V/8.3A |
| Engine Model | OHV |
| Engine Type | 4-stroke; air-cooled,gasoline |
| Max. Output | 7.0hp/3600rpm |
| Displacement Capacity | 208cc |
| Fuel Tank Capacity | 15L |
| Continuous Work | More Than 8h |
| Fuel Type | 90#Petrol |
| Spark Plug | F6TC |
| Starting System | Recoil/Electric |
| Noise Level at 7m | 69dB |
| Gross Weight | 49kg |
| Dimension | 605x470x465mm |
| 20FT Container QTY | 192 |
| 40HQ Container QTY | 495 |
| Certificate | CE ISO9001 |
| Color | Customized |
| Warranty | 1000 Working Days Guaranteed |
| Model | PFG1500 | PFG2500 | PFG5500 | PFG6500 | PFG7500 |
| Frequency | 50/60Hz | ||||
| Rated AC output(W) | 1000 | 2000 | 3000 | 5000 | 6000 |
| Max. AC output(W) | 1200 | 2200 | 3500 | 5500 | 6500 |
| AC voltage(V) | 110,120,220,230 | ||||
| DC Output (V/A) | 12/5.3 | 12/8.3 | |||
| Engine model | JP154 | JP168 | JP170 | JP188 | JP190 |
| Engine type | 4-stroke, aircooling,gasoliine | ||||
| Max. Output (hp/rpm) | 3.0/3600 | 5.5/3600 | 7.0/3600 | 13.0/3600 | 15.0/3600 |
| Displacement Capacity(cc) | 87 | 163 | 208 | 389 | 420 |
| Fuel tank capacity(L) | 12 | 15 | 15 | 25 | 25 |
| Continuous work (h) | 13 | 12.5 | 10.5 | 9 | 8.6 |
| Fuel type | 90#Petrol | ||||
| Spark Plug | E6TC | F6TC | F6TC | F6RE | F6RE |
| Starting system) | Recoil | Recoil/Electric | Recoil/Electric | Recoil/Electric | Recoil/Electric starter |
| Noise Level at 7m | 65 | 65 | 69 | 71 | 72 |
| Gross Weight(kg) | 28 | 42 | 49 | 95 | 98 |
| Dimension(mm) | 475x372x432 | 615x430x500 | 605x470x465 | 690x545x570 | 780x545x570 |
| 20FT Container QTY | 370 | 192 | 192 | 136 | 120 |
| 40HQ Container QTY | 918 | 500 | 495 | 288 | 252 |
Q1. Is your company a trade one or factory?
Answer:We are a professional OEM factory which has the only one full-fuction testing canter in morthern China.
Q2.How long has your company run on generator sets?
Answer:Our company was established in 1995.After the development of more than 15 years,we have become the leading
generator set manufacturer in northern China.
Q3.How to deal with the broken machine?
Answer: We provide professional technical response for your questions. we can make sure that the configuration, feature,
optional item can work smoothly. But maintenance freight needs paying by yourself.
Q4.What about your warranty?
Answer:One year guaranteed.During the warranty period,we will provide the free quick-wear parts for problems caused by our
quality and raw meterial.
Q5.What about other service?
Answer:a Good reputation for reliable quality and reasonable price.
b Advanced technology and production line with skilled workers
c As we have the only one full-function testing center in northern China,we must test and check the machine strictly
before shipment.
Dalian Puyang diesel generator set has the largest scale of production and full product specifications and models,which has the only one full-function testing center in northern China for more than 20 years.We still insist on the principle that let the light and power eternal.We would like to obtain your support and trust through our best quality of pruducts and service.
