Graphite Anode for Impressed Current Cathodic Protection

Specifications

Graphite anodes is a reliable impressed current auxiliary anode and are used extensively throughout the industry.

Graphite anodes have been a standard for cathodic protection for many years.



They are considered as a reliable impressed current anode and are used extensively throughout the industry. Low in cost, graphite anodes, used in conjunction with carbon anode backfill, provide long-term performance characteristics for many cathodic protection applications.



Dia50mm-100mmX1000mm-2030mm

Grain size: Less than 0.5mm
Real density: More than 1.72g/cm3
Porosity: Less than 20%
Bending strength: More than 20MPA
Resistance: Less than 7 u Ωm
Ash: Less than 0.3%



Grain size:       less than 0.5mm Real density:     more than 1.72g/cm3 Porosity:         less than 20% Bending strength: more than 20MPA Resistance:       less than 7 u Ωm Ash:              less than 0.3%               Dia50mmX1000mm               Dia65mmX1000mm               Dia65mmX1300mm               Dia75mmX762mm               Dia75mmX1320mm               Dia75mmX1524mm               Dia100mmX1016mm               Dia100mmX1320mm               Dia100mmX1600mm               Dia100mmX2032mm
